Propain EKANO 2 CF Mix Signature Spec 1 2025
2025 E-bike
Estimate price |
8,700$
Weight | 22.8 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 180mm -
Travel Rear 170mm -
Fork RockShox ZEB Ultimate
-
Groupset GX Eagle Transmission, Eagle 70 Transmission -
Suspension Full -
Motor SRAM hub-drive -
Drivetrain 1 × 12 -
Brakes Magura MT5 Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Blend Carbon - Raw Matte Finish
Suspension Fork
RockShox ZEB Ultimate
Rear Shock
RockShox Vivid Select+
Drivetrain
Rear Derailleur
SRAM Eagle 70
Cassette
SRAM GX Eagle Transmission
Crank
SRAM GX Eagle Transmission
Wheels
Rims
Crankbrothers SYNTHESIS E-BIKE ALLOY 27.5/29
Tires
Maxxis Assegai / DHR
Brakes
Brakes
Magura MT5
Cockpit
Stem
SIXPACK Millenium 35 ICR
Handlebar
One Up Carbon
Seat
Saddle
SIXPACK Kamikaze
Seatpost
One Up
Motor & Battery
Motor
SRAM Eagle Powertrain
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.505 mm | 1.446 mm | 1.395 mm | 1.359 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 786 mm | 808 mm | 830 mm | 855 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 146 mm | 148 mm | 148 mm | 147 mm |
| Stack | 647 mm | 652 mm | 657 mm | 666 mm |
| Reach | 430 mm | 451 mm | 471 mm | 490 mm |
| Seat Tube Angle | 77.6 ° | 77.6 ° | 77.6 ° | 77.6 ° |
| Head Tube Angle | 63.6 ° | 63.6 ° | 63.6 ° | 63.6 ° |
| Head Tube Length | 110 mm | 115 mm | 120 mm | 130 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1237 mm | 1259 mm | 1281 mm | 1306 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm | 10 mm |
| Standover Height | 827 mm | 824 mm | 821 mm | 819 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
