Propain TYEE 6 CF Shred² 2024
2024 Mountain
Estimate price |
5,914$
Weight | 13.8 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 170mm -
Travel Rear 160mm -
Fork RockShox ZEB Ultimate
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Blend Carbon Frame
Suspension Fork
RockShox ZEB Ultimate 170mm
Rear Shock
RockShox Super Deluxe Coil Ultimate
Drivetrain
Rear Derailleur
SRAM GX Eagle
Cassette
SRAM XG-1275 Eagle
Crank
Truvativ Descendant 170mm 32t
Wheels
Rims
DT Swiss EX 1700
Tires
Schwalbe Magic Mary / Big Betty
Brakes
Brakes
SRAM Code R 200 mm / 200 mm
Cockpit
Stem
SIXPACK Millenium 35
Handlebar
SIXPACK Millenium 805
Seat
Saddle
SIXPACK Kamikaze
Seatpost
BikeYoke Revive
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS High | SM High | MD High | MD High | LG High | XL High |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.422 mm | 1.381 mm | 1.334 mm | 1.365 mm | 1.313 mm | 1.265 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 715 mm | 748 mm | 780 mm | 787 mm | 816 mm | 846 mm |
| Rake | 37 mm | 37 mm | 37 mm | 44 mm | 44 mm | 44 mm |
| Trail | 129 mm | 130 mm | 129 mm | 130 mm | 130 mm | 130 mm |
| Stack | 576 mm | 594 mm | 607 mm | 621 mm | 630 mm | 639 mm |
| Reach | 405 mm | 430 mm | 455 mm | 455 mm | 480 mm | 505 mm |
| Top Tube Length | 528 mm | 559 mm | 588 mm | 592 mm | 620 mm | 647 mm |
| Seat Tube Angle | 77.9 ° | 77.7 ° | 77.6 ° | 77.5 ° | 77.5 ° | 77.4 ° |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 90 mm | 110 mm | 125 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1145 mm | 1178 mm | 1210 mm | 1231 mm | 1260 mm | 1290 mm |
| Bottom Bracket Drop | 11 mm | 11 mm | 11 mm | 27 mm | 27 mm | 27 mm |
| Standover Height | 776 mm | 776 mm | 776 mm | 776 mm | 776 mm | 776 mm |
| Wheels | 27" | 27" | 27" | 29" | 29" | 29" |
