Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Reba
-
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium frame
Suspension Fork
RockShox Reba, 140 mm
Rear Shock
RockShox Deluxe Select R 140mm
Wheels
Rims
Newmen Evolution X.A.25
Brakes
Brakes
SRAM Guide T 200mm / 180mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 24" | 26" |
|---|---|---|
| Stack Reach Ratio | 1.434 mm | 1.434 mm |
| Front Center | 679 mm | 679 mm |
| Rake | 42 mm | 42 mm |
| Stack | 545 mm | 545 mm |
| Reach | 380 mm | 380 mm |
| Top Tube Length | 526 mm | 526 mm |
| Seat Tube Angle | 75 ° | 75 ° |
| Head Tube Angle | 65 ° | 65 ° |
| Head Tube Length | 95 mm | 95 mm |
| Chainstay Length | 420 mm | 432 mm |
| Wheelbase | 1099 mm | 1111 mm |
| Bottom Bracket Drop | 3 mm | 3 mm |
| Standover Height | 662 mm | 687 mm |
| Wheels | 26" | 26" |
