Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 80mm -
Fork Suntour MOBIE
-
Suspension Hardtail -
Motor Bosch 600W 63Nm mid-drive -
Battery BOSCH "PowerPack 725", 725 Wh, BES3 -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
QIO EINS, Bosch Gen.3, BES3, aluminium, 49,5cm, christal white glossy
Suspension Fork
SR SUNTOUR suspension fork "SF22-Mobie34-CGO-Boost" 20", 80mm travel, tapered, 313mm shaft, post mount, boost, thru axle, matt black
Drivetrain
Shift Levers
ENVIOLO "Twist Pure Display", for TR hub, grey, stepless
Cassette
GATES "CDX", for Enviolo, 22 teeth
Crank
Stronglight "Mangan 3", 170mm, for Bosch Gen.3, BNI, aluminium, black
Bottom Bracket
Bosch, press-fit
Chain Guide
CURANA "C+", 55 teeth, Bosch Gen.3, plastic, 2 pieces, black
Pedals
UNION "SP-153", foldable
Wheels
Front Hub
SHIMANO front hub "Deore HB-TC500-15-C", 15 x 110mm, Center Lock, 36 holes, thru axle, black
Rear Hub
ENVIOLO "TR", 6-hole, 36 holes, black
Rims
DT SWISS "U 663", 30-406, 36 holes, disc brake, easy eyelets, tubeless ready, black
Spokes
Niro, schwarz
Tires
SCHWALBE "Marathon 365" Performance Line, 55-406, Green Guard, Addix 4Season, 67 TPI, E-50, reflex
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
BY.SCHULZ "Stem SDS", 1 1/8", 31,8mm handlebar clamp, 70mm long, angle 7°, black
Handlebar
ERGOTEC "Lady Town", 620mm, Ø 31,8mm, 30° backsweep, rise 16mm, Level 4, black
Grips
HERRMANS "Clik Original DD37", 90/123mm, handlebar clamp, black
Headset
CONTEC "Drop-A-Gogo", aluminium, Ø 31,6mm, 465mm long, 170mm, black
Seat
Saddle
SELLE ROYAL "Nuvola 5060", unisex, relaxed, black
Seatpost
BY.SCHULZ "G.2 ST", aluminium, Ø 34,9mm, 400mm long, 30mm travel, medium, 7mm clamp, theft protection, black
Motor & Battery
Motor
BOSCH Motor "Performance Line", Gen.3, BES3
Battery
BOSCH "PowerPack 725", 725 Wh, BES3
Remote
BOSCH "BRC3600", LED remote
Charger
BOSCH 4 A, BES3
