Rad Power Bikes RadCity 5 Plus High-Step 2024
2024 E-bike
Estimate price |
1,699$
Weight | 29.03 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 50mm -
Groupset Shimano -
Suspension Hardtail -
Motor 750W hub-drive -
Battery 14 Ah 672 Wh semi-integrated battery, tested by ACT compliant to UL 2271 -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
One Size
142cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
Spring fork, 50 mm travel, with lockout and preload adjustment
Drivetrain
Rear Derailleur
7-Speed Shimano
Shift Levers
7-speed thumb shifter
Cassette
7-speed freewheel, 11-34T
Crank
46T wtih dual-sided aluminum bashguard, 170 mm forged alloy
Bottom Bracket
84 mm, Square taper bottom bracket
Chain
KMC Z7
Pedals
Forged aluminum platform with reflectors, standard 9/16" x 20 TPI threading
Wheels
Rims
Double wall aluminum alloy, 36H
Spokes
Rear: 12-gauge stainless steel, Front: 14-gauge stainless steel
Tires
27.5" x 2.0", e-bike rated with puncture-resistant liner *tires received may not include branding
Brakes
Brakes
Rad Power Bikes approved hydraulic brake caliper (and levers)
Brake Levers
Rad Power Bikes approved aluminum alloy levers with motor cutoff switch. Reach adjustable (2.5 mm Allen wrench)
Cockpit
Stem
Zoom, 90º angle adjustment, 90 mm length, Tiger Orange: not adjustable
Handlebar
Aluminum, 680 mm wide, Tiger Orange: 720mm, straighter bars with less sweep
Grips
Ergonomic imitation leather comfort grips
Headset
Semi-integrated, 1-1/8" straight steerer tube
Seat
Saddle
Rad Power Bikes with lifting handle
Seatpost
350 mm x 27.2 mm
Motor & Battery
Motor
Rear hub 750W, Stated wattage is the manufacturer’s rated power capacity. Actual power-to-ground wattage is under 750W to ensure ebike regulatory compliance and may vary depending on riding conditions.
Battery
14 Ah 672 Wh semi-integrated battery, tested by ACT compliant to UL 2271
Remote
Rad Power Bikes frame-integrated controller
Charger
48V, 2 Amp Rad Power Bikes smart charger, operates on 100V-240V AC power outlets
Fit data
Geometry
