Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4129 Chromoly, Tapered Head Tube
Suspension Fork
Custom Alloy SPF Road, 1-1/8" to 1-1/2" Taper
Drivetrain
Rear Derailleur
Shimano Claris
Front Derailleur
Shimano Claris
Shift Levers
Shimano Claris 8 Speed
Cassette
Shimano 8 Speed, 11-30
Crank
Shimano Claris Compact 34/50
Bottom Bracket
Shimano Octalink
Chain
KMC Z82
Pedals
Alloy Body with Alloy Cage
Wheels
Front Hub
Alloy, Quick Release 28 Hole
Rear Hub
Alloy, Cassette, Quick Release, 28 Hole
Rims
Alloy,Double Wall, 23mm Wide
Spokes
14g Stainless Steel
Tires
Clement Strada LGG 60TPI, 700x28c
Brakes
Brakes
Promax Long-Reach Dual Pivot
Brake Levers
Shimano Claris STI
Cockpit
Stem
Alloy, 3D Forged, 31.8, 7 Degree +/-, 80/90/100mm
Handlebar
Alloy Road, 31.8 Short Drop, Polished, 38/40cm
Headset
Sealed Cartridge Bearings, Integrated
Seat
Saddle
Brooks Cambium C17 Women's
Seatpost
Alloy Micro Adjust, 27.2x300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.5 mm | 1.54 mm | 1.56 mm |
| Bottom Bracket Height | 256 mm | 266 mm | 261 mm | 263 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 530 mm | 540 mm | 555 mm | 569 mm |
| Reach | 363 mm | 359 mm | 360 mm | 365 mm |
| Top Tube Length | 494 mm | 509 mm | 514 mm | 534 mm |
| Seat Tube Angle | 76 ° | 74.5 ° | 74.5 ° | 73.5 ° |
| Seat Tube Length | 450 mm | 475 mm | 500 mm | 525 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 71 ° |
| Head Tube Length | 150 mm | 130 mm | 145 mm | 160 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm |
| Bottom Bracket Drop | 80 mm | 70 mm | 75 mm | 72 mm |
| Standover Height | 695 mm | 717 mm | 745 mm | 771 mm |
| Wheels | 700 | 700 | 700 | 700 |
About this model
Addison completes the Raleigh Addison model. Raleigh launched 2 bikes of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Endurance bikes average price
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Raleigh released this model in 2019, its price was 799$. If we compare this with the average Endurance bike cost we notice that the price is 193.62% lower.
Overview of components
Fork material
Addison has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
The Addison 2019 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Addison is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
