Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 700c -
Suspension Rigid -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 Double Butted Chromoly, Intergrated Headtube w/Eccentric BB
Suspension Fork
4130 Chromoly Cross, w/Disc Tabs, 1-1/8"
Drivetrain
Crank
Forged 2pc, 42t
Bottom Bracket
FSA BSA Eccentric w/Sealed Bearings
Chain
KMC Z51
Pedals
Test Ride Pedals
Wheels
Front Hub
Joytech Alloy Disc QR 32h
Rear Hub
Joytech Alloy Disc, Cassette, QR, 32h
Rims
Weinmann XC180 Double Wall 32h
Spokes
14g Stainless w/Brass Nipples
Tires
Clement X'PLOR USH, 700x35, 60 TPI
Brakes
Brakes
Promax Render R Disc w/160 Rotors
Brake Levers
Tektro RL-340
Cockpit
Stem
Raleigh 200 Series, 3D Forged, 31.8, Lengths:90/90/100/100/110/110mm
Handlebar
Raleigh 200 Series 31.8 Short Drop, Widths:40/40/42/42/44/44cm
Headset
FSA Integrated Cartridge Bearings
Seat
Saddle
Raleigh Classic Road
Seatpost
Raleigh 6061 Alloy Dual Bolt 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.48 mm | 1.5 mm | 1.56 mm | 1.54 mm | 1.55 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Stack | 538 mm | 561 mm | 577 mm | 608 mm | 621 mm | 632 mm |
| Reach | 382 mm | 380 mm | 385 mm | 390 mm | 404 mm | 407 mm |
| Top Tube Length | 526 mm | 546 mm | 561 mm | 576 mm | 591 mm | 606 mm |
| Seat Tube Angle | 75 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 100 mm | 125 mm | 140 mm | 165 mm | 180 mm | 200 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Bottom Bracket Drop | 67 mm | 65 mm | 65 mm | 62 mm | 62 mm | 62 mm |
| Standover Height | 771 mm | 791 mm | 811 mm | 831 mm | 851 mm | 866 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Furley is a Raleigh Furley model. Raleigh launched 1 bike of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
General Urban bikes average price
If you want an acceptable General Urban bike you should know that the average price is 499$. However, this doesn’t mean that if you spend less money on a General Urban bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2017 for 649$. Doing a quick comparison, we notice that Furley price is 30.06% higher than the average cost of a General Urban bike.
Overview of components
Fork material
The fork on this bike is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
When it comes to wheels, the Furley bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Furley has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
