Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 Chromoly Road Long Reach Brake
Suspension Fork
Custom Chromoly Road, Long Reach Brake
Drivetrain
Rear Derailleur
Shimano Claris
Front Derailleur
Shimano Claris
Shift Levers
Shimano Claris 8spd STI, Shimano SP41 Shift Housing
Crank
Shimano Claris Compact 34/50t
Bottom Bracket
Shimano Octalink
Chain
KMC Z82
Pedals
Test Ride Pedals
Wheels
Front Hub
Formula Alloy QR 28h
Rear Hub
Formula Alloy QR 28h Cassette
Rims
Weinmann GMax Double Wall 23mm Wide
Spokes
14g Stainless Steel
Tires
Kenda Kwick Roller Sport Folding Bead, 60TPI, 700x28c
Brakes
Brakes
Promax Custom Long-Reach Dual Pivot w/Sure Stop Pads
Brake Levers
Shimano Claris STI
Cockpit
Stem
Raleigh 7° 3D Forged, 31.8, 90/100/110mm
Handlebar
Raleigh 200 Series Road, 31.8 Short Drop, Polished, 40/42/44cm
Grips
Gel Tape
Headset
FSA Orbit UF
Seat
Saddle
Raleigh Classic Road
Seatpost
Raleigh 100 Series 27.2x300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|
| Bottom Bracket Height | 263 mm | 263 mm | 266 mm | 266 mm | mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Top Tube Length | 541 mm | 556 mm | 571 mm | 586 mm | 601 mm |
| Seat Tube Angle | 73 ° | 73 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 520 mm | 560 mm | 600 mm | 600 mm | 620 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 160 mm | 175 mm | 210 mm | 210 mm | 230 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | mm |
| Standover Height | 791 mm | 806 mm | 826 mm | 621 mm | 866 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
GRAND SPORT (2015) is part of the Raleigh Grand Sport model. 3 bikes variations carry this model name so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for General Road bikes
According to our calculations, the average cost of a General Road bike that is reliable is 1915$. However, you could also get a good General Road bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 639$. In conclusion, this bike price is 199.69% lower than the price of the average General Road bike.
GRAND SPORT (2015) components
Fork material
GRAND SPORT (2015) has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
The wheels on GRAND SPORT (2015) are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
