Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 Chromoly, Tapered Head Tube
Suspension Fork
Custom Alloy SPF Road, 1-1/8" to 1-1/2" Taper
Drivetrain
Rear Derailleur
Shimano Claris
Front Derailleur
Shimano Claris
Shift Levers
Shimano Claris 8 Speed
Cassette
Shimano 8 Speed, 11-30
Crank
Shimano Claris Compact 34/50
Bottom Bracket
Shimano Octalink
Chain
KMC Z82
Pedals
Alloy Body with Alloy Cage
Wheels
Front Hub
Alloy, Quick Release 28 Hole
Rear Hub
Alloy, Cassette, Quick Release, 28 Hole
Rims
Alloy,Double Wall, 23mm Wide
Spokes
14g Stainless Steel
Tires
Clement Strada LGG 60TPI, 700x28c
Brakes
Brakes
Promax Long-Reach Dual Pivot
Brake Levers
Shimano Claris STI
Cockpit
Stem
Alloy, 3D Forged, 31.8, 7 Degree +/-, 90/100/110mm
Handlebar
Alloy Road, 31.8 Short Drop, Polished, 40/42/44cm
Headset
Sealed Cartridge Bearings, Integrated
Seat
Saddle
Brooks Cambium C19 with Tubular Steel Rail
Seatpost
Alloy Micro Adjust, 27.2x300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.55 mm | 1.55 mm | 1.57 mm | 1.58 mm | 1.59 mm |
| Bottom Bracket Height | 261 mm | 263 mm | 263 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 593 mm | 600 mm | 609 mm | 623 mm | 636 mm | 652 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 69 mm | 66 mm | 63 mm | 63 mm | 62 mm | 63 mm |
| Stack | 552 mm | 570 mm | 586 mm | 603 mm | 617 mm | 636 mm |
| Reach | 363 mm | 367 mm | 377 mm | 384 mm | 391 mm | 401 mm |
| Top Tube Length | 521 mm | 541 mm | 556 mm | 571 mm | 586 mm | 601 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 140 mm | 160 mm | 175 mm | 195 mm | 210 mm | 230 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1013 mm | 1020 mm | 1030 mm | 1044 mm | 1057 mm | 1073 mm |
| Bottom Bracket Drop | 75 mm | 72 mm | 72 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 771 mm | 791 mm | 806 mm | 826 mm | 846 mm | 866 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Grand Sport belongs to the Raleigh Grand Sport model. Raleigh launched 3 bikes of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
General Road bikes average price
According to our calculations, the average cost of a General Road bike that is reliable is 1915$. However, you could also get a good General Road bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2018 and its price was 799$. Comparing the average cost of a General Road bike to this one, you will see that Grand Sport price is 139.67% lower.
Overview of components
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
The Grand Sport 2018 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Grand Sport has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
