Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 20" / 26" -
Groupset Acera, Altus -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Classic Steel with fixed front rack, Disc Tabs
Suspension Fork
Tubular Steel with Disc Tabs
Drivetrain
Rear Derailleur
Shimano Acera
Shift Levers
Shimano 8 Speed, SL-M310 Right Only
Cassette
Shimano 8 Speed, 11-34
Crank
Alloy Forged 3PC 104BCD, 40t
Bottom Bracket
Cartridge 68/110
Chain
KMC 8 Speed
Pedals
Alloy Body, Cromo Spindle
Wheels
Front Hub
Alloy, Nutted Disc, 36 Hole
Rear Hub
Alloy, Nutted Disc, 36 Hole
Rims
Alex DX32, Double Wall, 36 Hole, 20" Front, 26" Rear
Spokes
14g Stainless Steel w/Brass Nipples
Tires
Kenda K 1164, 20x2.4 Front, 26x2.4 Rear
Brakes
Brake Levers
Alloy
Cockpit
Stem
Alloy Die Cast, 25.4 Bar Bore, 25 Degree Rise, 90mm Extention
Handlebar
Alloy, 25.4, 66mm Rise, 610mm Wide, 43 Degree Backsweep
Grips
MTB Lock-On with End Plugs
Seat
Saddle
Raleigh Weather Resistant Saddle
Seatpost
Alloy Micro Adjust, 27.2 x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.56 mm |
| Front Center | 687 mm |
| Rake | 50 mm |
| Stack | 610 mm |
| Reach | 392 mm |
| Top Tube Length | 626 mm |
| Seat Tube Angle | 69 ° |
| Seat Tube Length | 520 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 370 mm |
| Chainstay Length | 481 mm |
| Wheelbase | 1162 mm |
| Bottom Bracket Drop | 60 mm |
| Standover Height | 681 mm |
| Wheels | 20" |
| Rider Min Height | 120 cm |
Model Overview
Lorry belongs to the Raleigh Lorry model. 2 bikes variations carry this model name so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Utility bikes average price
If you want an acceptable Utility bike you should know that the average price is 1069$. However, this doesn’t mean that if you spend less money on an Utility bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2018 for 699$. Comparing the average cost of an Utility bike to this one, you will see that Lorry price is 52.93% lower.
Lorry components
Fork material
When it comes to the fork, this bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
The Lorry 2018 bike is equipped with 20″ aluminum wheels when leaving the factory. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Lorry is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
