Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 20" / 26" -
Groupset Acera, Altus -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Classic Steel with fixed front rack, Disc Tabs
Suspension Fork
Tubular Steel with Disc Tabs
Drivetrain
Rear Derailleur
Shimano Acera
Shift Levers
Shimano 8 Speed, SL-M310 Right Only
Cassette
Shimano 8 Speed, 11-34
Crank
Alloy Forged 3PC 104BCD, 40t
Bottom Bracket
Cartridge 68/110
Chain
KMC 8 Speed
Pedals
Alloy Body, Cromo Spindle
Wheels
Front Hub
Alloy, Nutted Disc, 36 Hole
Rear Hub
Alloy, Nutted Disc, 36 Hole
Rims
Alex DX32, Double Wall, 36 Hole, 20" Front, 26" Rear
Spokes
14g Stainless Steel w/Brass Nipples
Tires
Kenda K 1164, 20x2.4 Front, 26x2.4 Rear
Brakes
Brakes
Tektro MD300 Mechanical Disc
Brake Levers
Alloy
Cockpit
Stem
Alloy Die Cast, 25.4 Bar Bore, 25 Degree Rise, 90mm Extention
Handlebar
Alloy, 25.4, 66mm Rise, 610mm Wide, 43 Degree Backsweep
Grips
MTB Lock-On with End Plugs
Seat
Saddle
Raleigh Weather Resistant Saddle
Seatpost
Alloy Micro Adjust, 27.2 x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.56 mm |
| Front Center | 687 mm |
| Rake | 50 mm |
| Stack | 610 mm |
| Reach | 392 mm |
| Top Tube Length | 626 mm |
| Seat Tube Angle | 69 ° |
| Seat Tube Length | 520 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 370 mm |
| Chainstay Length | 481 mm |
| Wheelbase | 1162 mm |
| Bottom Bracket Drop | 60 mm |
| Standover Height | 681 mm |
| Wheels | 20" |
| Rider Min Height | 120 cm |
About this model
Lorry is part of the Raleigh Lorry model. There are 2 bikes that carry this model name.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Utility bikes average price
Our math shows that the average cost of a dependable Utility bike is 1069$. However, even though the average price of an Utility bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Raleigh Lorry price was 699$. Doing a quick comparison, we notice that Lorry price is 52.93% lower than the average cost of an Utility bike.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
The Lorry 2019 bike is equipped with 20″ aluminum wheels when leaving the factory. The 20″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
When you want to stop the bike in time, the brakes are vital. The Lorry has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
