Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Travel Front 135mm -
Groupset Alivio, Sora -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom Steel frame w/ Machined HT, IS Disc Mount, 170mm dropout
Suspension Fork
Custom Steel Fat Bike Fork, IS Disc Mount, 135mm
Drivetrain
Rear Derailleur
Shimano Alivio Shadow 9spd
Front Derailleur
Shimano Alivio Top Swing
Shift Levers
Shimano Alivio 9spd
Cassette
Shimano (12-36) 9spd
Crank
Shimano FC-M3000, 40/30/22t 170/175
Bottom Bracket
VP E Type 100mm
Chain
KMC X9 Anti-Rust
Pedals
Alloy Platform Pedals
Wheels
Front Hub
Joytech Disc 32h, 135mm Nutted
Rear Hub
Joytech Disc 32h, 170mm Nutted
Rims
Raleigh Prospect 80, 26X32h, 73mm wide
Spokes
14g Stainless Steel, Black w/ Brass Nipples
Tires
CY Fat Bike Tire, 26X4.0
Brakes
Brakes
Tektro Mira Mechanical Disc Brakes w/160mm Rotors
Brake Levers
Tektro Alloy
Cockpit
Stem
Raleigh 3D Forged Alloy, 60mm
Handlebar
Raleigh 200 Series MTB Riser, 31.8, Width:S 720mm, 740mm other sizes
Grips
Foam Grip Black
Headset
FSA Orbit CE Sealed
Seat
Saddle
Raleigh Mountain Saddle, 140mm wide
Seatpost
Raleigh 100 Series, Dual Bolt, 30.9x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm |
| Front Center | 655 mm | 675 mm | 697 mm | 716 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Top Tube Length | 587 mm | 607 mm | 627 mm | 647 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 390 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 110 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 467 mm | 467 mm | 467 mm | 467 mm |
| Wheelbase | 1115 mm | 1135 mm | 1157 mm | 1177 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 792 mm | 797 mm | 822 mm | 837 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Pardner completes the Raleigh Pardner model. Raleigh launched 1 bike of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Fatbike bikes average price
According to our calculations, the average cost of a Fatbike bike that is reliable is 1743$. However, even though the average price of a Fatbike bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Raleigh Pardner price was 799$. If we compare this with the average Fatbike bike cost we notice that the price is 118.15% smaller.
Pardner components
Fork material
When it comes to the fork, this bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
When leaving the production line, the Pardner model has 26″ aluminum wheels. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Raleigh Pardner has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
