Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 520 Butted Chromoly Tubing
Suspension Fork
4130 Chromoly Cross
Drivetrain
Rear Derailleur
Shimano Sora
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora 9spd STI, Shimano SP41 Shift housing
Cassette
Shimano 9spd (11-32t)
Crank
Shimano Sora 2pc 46/34t
Bottom Bracket
Shimano External Bearing
Chain
KMC Z99
Pedals
Steel Clips w/Leather Straps
Wheels
Front Hub
Formula Alloy QR 28h
Rear Hub
Formula Alloy QR 28h Cassette
Rims
Weinmann GMax Double Wall
Spokes
14g Stainless Steel
Tires
Kenda Karvs 700x28c, 60TPI Wire Bead
Brakes
Brakes
Tektro CR710 Cantilever
Brake Levers
Promax XL-102 w/Hidden Bar Clamp Bolt
Cockpit
Stem
Raleigh 15° Forged, 25.4
Handlebar
Steel 66mm Rise, 43° Back Sweep
Grips
Black DuraCork
Headset
FSA Orbit DL 1-1/8" Threadless
Seat
Saddle
Raleigh Classic Road w/Satin Steel Rails
Seatpost
Raleigh 100 Series 27.2x300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 53cm | 55cm | 57cm | 59cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.44 mm | 1.48 mm | 1.5 mm | 1.49 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 543 mm | 552 mm | 563 mm | 582 mm | 601 mm |
| Reach | 386 mm | 383 mm | 380 mm | 389 mm | 403 mm |
| Top Tube Length | 525 mm | 535 mm | 545 mm | 565 mm | 585 mm |
| Seat Tube Angle | 75.5 ° | 74.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 500 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 775 mm | 785 mm | 805 mm | 825 mm | 845 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Port Townsend is part of the Raleigh Port model. 3 bikes variations carry this model name so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for General Urban bikes
According to our calculations, the average cost of a General Urban bike that is reliable is 499$. However, you could also get a good General Urban bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 749$. Comparing this to the average General Urban bike price, we see that the price is 50.1% more expensive.
Overview of components
Fork material
The fork on this bike is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
When leaving the production line, the Port Townsend model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Port Townsend has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
