Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 700c -
Suspension Rigid -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Classic Steel, Eccentric BB, Disc Tabs
Suspension Fork
Classic Steel, Disc
Drivetrain
Cassette
Raleigh Heron 42 Tooth
Crank
Forged Alloy, 170mm
Bottom Bracket
Sealed Cartridge
Chain
KMC Z410
Pedals
VP Classic
Wheels
Front Hub
Alloy, 32 Hole Nutted, Disc
Rear Hub
Alloy, 32 Hole, Nutted, Disc
Rims
Alloy, Double Wall, 700c, 32 Hole
Spokes
14g
Tires
Kenda Bitumen, 700x45c, Urban Brown
Brakes
Brakes
Tektro Cable Acuated Mechanical Disc
Brake Levers
Promax Alloy
Cockpit
Stem
Alloy, Silver Anodized Quill, 90mm Extension, 35 Degree Rise
Handlebar
Steel Reversible Hi-Low Bar, Copper Finnish
Grips
Comfort Lock-On
Headset
Silver, 1-1/8" Threaded
Seat
Saddle
Raleigh Vintage Leather with Classic Springs
Seatpost
Alloy, 25.6x300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.35 mm | 1.35 mm |
| Front Center | 613 mm | 629 mm | 653 mm |
| Rake | 60 mm | 60 mm | 60 mm |
| Trail | 54 mm | 62 mm | 57 mm |
| Stack | 521 mm | 542 mm | 560 mm |
| Reach | 384 mm | 401 mm | 414 mm |
| Top Tube Length | 547 mm | 567 mm | 587 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 550 mm | 570 mm | 590 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 90 mm | 110 mm | 130 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1054 mm | 1070 mm | 1094 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm |
| Standover Height | 788 mm | 808 mm | 826 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Preston is part of the Raleigh Preston model. Raleigh released 1 bike variation of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for General Urban bikes
According to our math, the average price for a trustworthy General Urban bike is 499$. However, paying less money than this amount doesn’t mean that you couldn’t get a great General Urban bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2018 for 599$. Doing a quick comparison, we notice that Preston price is 20.04% higher than the average cost of a General Urban bike.
Preston components
Fork material
The fork on this bike is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
When it comes to wheels, the Preston bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Preston has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Preston comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
