Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Veloce -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 631 Double Butted Chromoly
Suspension Fork
Flat Crown Lugged 4130 Chromoly Road, Long Reach Brake
Drivetrain
Rear Derailleur
Campagnolo Veloce
Front Derailleur
Campagnolo Veloce
Shift Levers
Campagnolo Veloce 10spd Ergopower, Jagwire Shift Housing
Cassette
Campagnolo Veloce 10spd (13-29t)
Crank
Campagnolo Veloce Power-Torque CT 34/50t
Bottom Bracket
Campagnolo Power-Torque Outboard Cups
Chain
KMC X10
Pedals
Test Ride Pedals
Wheels
Front Hub
Joytech Alloy Sealed Bearing 24h, Retro Style QR
Rear Hub
Joytech Alloy 4 Sealed Bearing 28h Campagnolo Cassette, Retro Style QR
Rims
Weinmann XP24, Double Wall 23mm Wide, High Polish Finish
Spokes
Double Butted Stainless 14/15g MAC
Tires
Kenda Kwick Roller Sport Folding Bead, 60TPI, 700x28c
Brakes
Brakes
Promax Custom Long-Reach Dual Pivot w/Sure Stop Pads
Brake Levers
Campagnolo Veloce Ergopower
Cockpit
Stem
Raleigh 7° 3D Forged, 31.8 90/100/110mm
Handlebar
Raleigh 200 Series Road, 31.8 Short Drop, Polished, 40/42/44cm
Headset
FSA Orbit UF
Seat
Saddle
Raleigh Classic Road
Seatpost
Raleigh 100 Series 27.2x300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.55 mm | mm | mm | mm | mm |
| Bottom Bracket Height | 261 mm | 263 mm | 263 mm | 266 mm | 266 mm | 266 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 552 mm | 570 mm | mm | mm | mm | mm |
| Reach | 365 mm | 368 mm | mm | mm | mm | mm |
| Top Tube Length | 521 mm | 541 mm | 556 mm | 571 mm | 586 mm | 601 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 140 mm | 160 mm | 175 mm | 195 mm | 210 mm | 230 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Bottom Bracket Drop | 75 mm | 72 mm | 72 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 771 mm | 791 mm | 806 mm | 826 mm | 846 mm | 866 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Record Ace belongs to the Raleigh Record model. There is 1 bike that carries this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Endurance bikes
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2017 for 1699$. Comparing the average cost of an Endurance bike to this one, you will see that Record Ace price is 38.08% lower.
Record Ace components
Fork material
When it comes to the fork, this bike has a steel one, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
The wheels on Record Ace are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Record Ace has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
