Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora, FSA -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy Endurance Road, Thru-Axle, Flat Mount Disc, Taper Headtube
Suspension Fork
Alloy SPF Formed, Tapered Steerer, 12mm Thru-Axle, Flat Mount Disc
Drivetrain
Rear Derailleur
Shimano Sora RD-R3000, 9 Speed
Front Derailleur
Shimano Sora FD-R3000, 31.8mm Band Clamp
Shift Levers
Shimano Sora ST-R3000 Dual Control, 2x9 Speed
Cassette
Shimano HG400 Cassette, 9 Speed, 11-32T
Crank
FSA Vero Compact, 50/34T
Bottom Bracket
Sealed Cartridge Square Taper
Chain
KMC X9
Pedals
Resin Platform Pedal
Wheels
Front Hub
Alloy Disc, 12mm Thru-Axle, 28h
Rear Hub
Alloy Disc, Thru-Axle, 28 Hole, Cassette
Rims
Raleigh Alloy Double Wall, 700c, 28 Hole
Spokes
14g Stainless with Brass Nipples
Tires
Chao Yang Rapide, Wire Bead, 700x28c
Brakes
Brakes
Tektro Lyra Flat Mount Mechanical Disc, w/160mm Rotors
Brake Levers
Shimano Sora
Cockpit
Stem
Alloy Road, 7°, 31.8
Handlebar
Alloy Road, Butted, 31.8
Headset
Integrated Cartridge Bearings
Seat
Saddle
Raleigh Woman's200 Series Saddle
Seatpost
Alloy Micro Adjust 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.44 mm | 1.51 mm | 1.52 mm | 1.54 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 263 mm | 266 mm | 266 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 502 mm | 527 mm | 548 mm | 562 mm | 583 mm |
| Reach | 362 mm | 365 mm | 364 mm | 370 mm | 378 mm |
| Top Tube Length | 501 mm | 516 mm | 526 mm | 541 mm | 556 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 435 mm | 460 mm | 485 mm | 510 mm | 535 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 105 mm | 130 mm | 150 mm | 165 mm | 185 mm |
| Chainstay Length | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 70 mm | 70 mm |
| Standover Height | 706 mm | 731 mm | 756 mm | 776 mm | 801 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Revere 2 completes the Raleigh Revere model. There are 6 bikes that carry this model name.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Endurance bikes
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Raleigh Revere 2 price was 799$. Doing a quick comparison, we notice that Revere 2 price is 193.62% smaller than the average cost of an Endurance bike.
Overview of components
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The wheels on Revere 2 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Revere 2 comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
