Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Suspension Rigid -
Motor 350W mid-drive -
Battery 48V Lithium-ion, 8.7Ah, 417Wh
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Wheels
Rims
700c
Motor & Battery
Motor
Currie Electro-Drive Centerdrive 350W
Battery
48V Lithium-ion, 8.7Ah, 417Wh
Remote
LCD multi-functional display
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | LG | MD | SM |
|---|---|---|---|
| Stack Reach Ratio | 1.604 mm | 1.617 mm | 1.577 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Stack | 627 mm | 642 mm | 642 mm |
| Reach | 391 mm | 397 mm | 407 mm |
| Top Tube Length | 590 mm | 606 mm | 616 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 400 mm | 430 mm | 480 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 145 mm | 160 mm | 160 mm |
| Chainstay Length | 480 mm | 480 mm | 480 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 715 mm | 742 mm | 780 mm |
| Wheels | 700 | 700 | 700 |
Model Overview
Route iE completes the Raleigh E Route model. 1 e-bike variation carries this model name so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Hybrid e-bikes average price
According to our calculations, the average cost of a Hybrid e-bike that is reliable is 2480$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
When Raleigh released this model in 2017, its price was 2699$. Doing a quick comparison, we notice that Route iE price is 8.83% more expensive than the average cost of a Hybrid e-bike.
Route iE components
Wheels
As for the wheels, Raleigh Route iE 2017, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
