Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset Alivio, FSA -
Suspension Full -
Motor Bosch 250W 50Nm mid-drive -
Battery Bosch Powertube 400Wh, DT Mount -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fully Formed Lightweight Aluminum Alloy 6061 T6, Nested ST Battery
Suspension Fork
Aluminum Alloy Oversize Blades, Disc Brake Mounts
Rear Shock
*
Drivetrain
Rear Derailleur
Shimano Alivio SGS, 9 Speed
Front Derailleur
*
Shift Levers
Shimano Alivo, Rapidfire Plus, 9 Speed
Cassette
FSA 42 Tooth w/Chainguard
Crank
FSA Cast Alloy, 170mm
Bottom Bracket
*
Chain
KMC x9ePT Ebike Specific
Pedals
Urban Style, Steel Cage w/Resin Body
Wheels
Front Hub
Formula, Alloy, w/QR 36 Hole
Rear Hub
Formula, Alloy, w/QR 36 Hole
Rims
Alloy Double Wall, 36 Hole
Spokes
Black w/Silver Nipples
Tires
Schwalbe Supermoto-X 27.5x2.40
Brakes
Brakes
Tektro Hydraulic Disc 160mm
Brake Levers
Tektro Hydraulic Ergo 4 Finger
Cockpit
Stem
Alloy Adjustable Height, Comfort Stem
Handlebar
Raleigh Aluminum Alloy
Grips
Raleigh Ergo Comfort Control
Headset
Integrated, Sealed Mechanism
Seat
Saddle
Raleigh Custom Ergo Comfort
Seatpost
Raleigh Aluminum Alloy, Forged Head
Motor & Battery
Motor
Bosch Active Line Plus, 50Nm Torque, 20 mph, Made in EU
Battery
Bosch Powertube 400Wh, DT Mount
Remote
Bosch Purion, Performance Line
Charger
Bosch Compact Charger 2 Amp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.6 mm | 1.61 mm |
| Front Center | 663 mm | 678 mm | 695 mm |
| Rake | 43 mm | 43 mm | 43 mm |
| Trail | 74 mm | 74 mm | 74 mm |
| Stack | 631 mm | 649 mm | 668 mm |
| Reach | 398 mm | 406 mm | 416 mm |
| Top Tube Length | 593 mm | 607 mm | 623 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 410 mm | 460 mm | 510 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 473 mm | 473 mm | 473 mm |
| Wheelbase | 1130 mm | 1145 mm | 1162 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 403 mm | 403 mm | 403 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Venture iE completes the Raleigh E Venture model. Raleigh released 3 e-bikes variations of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Comfort e-bikes
If you want an acceptable Comfort e-bike you should know that the average price is 1957$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Comfort e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
When Raleigh released this model in 2021, its price was 2850$. Comparing the average cost of a Comfort e-bike to this one, you will see that Venture iE price is 45.63% more expensive.
Overview of components
Fork material
The fork on this e-bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
The wheels on Venture iE are the aluminum type. After 700c wheels, 650b is the second most popular choice for road bikes. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Venture iE comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
