Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Travel Front 100mm -
Fork Manitou Circus Comp
-
Groupset Avid -
Suspension Hardtail -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full 4130 Chromoly with Mid BB and integrated headtube
Suspension Fork
Manitou Circus Comp 26” fork with 100mm of travel, 20mm Hex TA thru axle
Drivetrain
Shift Levers
Single Speed/Avid DB5 levers
Cassette
25T
Crank
Redline Monster chromoly 170mm, 19mm spindle
Bottom Bracket
68mm Mid BB
Chain
KMC K810
Wheels
Rims
Alex FR-30 26" double wall, front hub alloy loose ball 32H with 20mm thru axle, alloy sealed bearing single speed cassette, 135mm OLD
Tires
Schwalbe Table Top with Kevlar Guard
Brakes
Brakes
Avid DB1 hydrolic disc, 160mm rotor (rear brake only)
Cockpit
Stem
FSA Gap 45MM, 31.8mm clamp, +/- 8 degree
Handlebar
FSA Gap gravity high rise
Grips
Redline Monster
Headset
FSA Impact, Integrated with Angular Contact Bearings
Seat
Saddle
Monster Pivitol padded
Seatpost
Pivotal alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
About this model
D26 completes the Redline D26 model. There are 4 bikes that carry this model name.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Dirt Jump bikes
Our math shows that the average cost of a dependable Dirt Jump bike is 863$. However, this doesn’t mean that if you spend less money on a Dirt Jump bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2015 and its price was 1099$. If we compare this with the average Dirt Jump bike cost we notice that the price is 27.35% more expensive.
Overview of components
Fork
Redline D26 2015 bike is equipped with the Manitou Circus Comp fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When it comes to wheels, the D26 bike is equipped with the 26″ aluminum model. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
Nothing is more important on a bike than its ability to brake properly. Redline D26 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
