Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCR 32
-
Groupset Alivio, Acera -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Aluminum with Hydroformed Downtube and forged drop-outs with replaceable derailleur hanger
Suspension Fork
SR Suntour XCR 32 with 100mm travel and Hydrulic Lockout
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
Shimano Acera
Shift Levers
Shimano Alivio 9sp
Cassette
Shimano HG20 9sp, 11-32t
Crank
Shimano M371, 42/34/24t
Bottom Bracket
Square Tapered 68mm, 113L
Chain
KMC Z99
Wheels
Rims
Alex XD Elite double wall 29" - 32H, Pin Joint, Formula QR hubs
Tires
Kenda Small Block 8, 29 x 2.1
Brakes
Brakes
Shimano M396 hydraulic disc brakes with 160mm
Cockpit
Stem
XLC Alloy with 4 bolt clamp - 31.8mm
Handlebar
XLC Flat alloy, 31.8mm X 720mm width
Grips
Dual Compound 125mm width
Headset
FSA ZS-4, 1 1/8" Zero stack integrated
Seat
Saddle
XLC MTB padded, Steel rail
Seatpost
XLC alloy 27.2mm, 350mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" |
|---|---|---|---|---|
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 645 mm | 649 mm | 658 mm | 678 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Top Tube Length | 573 mm | 593 mm | 613 mm | 633 mm |
| Seat Tube Angle | 74.25 ° | 73.25 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 430 mm | 475 mm | 530 mm |
| Head Tube Angle | 71 ° | 71.25 ° | 72 ° | 72 ° |
| Head Tube Length | 90 mm | 95 mm | 100 mm | 105 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1085 mm | 1089 mm | 1098 mm | 1118 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 748 mm | 780 mm | 807 mm | 838 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
D606 completes the Redline D606 model. Redline released 2 bikes variations of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
D606 components
Fork
The SunTour XCR 32 is included from the factory. It has a travel distance of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Redline D606 2015, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Redline D606 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
