Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Fork RockShox Reba -
Groupset SLX -
Suspension Hardtail -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full carbon fiber utilizing RCT Monocoque construction, internal cable routing, BB92 press fit bottom bracket, tapered headtube and 12 x 142mm rear spacing
Suspension Fork
RockShox Reba RLT 29" Dual Air with tapered steerer
Drivetrain
Rear Derailleur
Shimano SLX 10s
Front Derailleur
Shimano SLX double, 31.8mm clamp
Shift Levers
Shimano SLX 10s
Cassette
Shimano 10s, 11-34t
Crank
Shimano SLX Hollow Tech, 10s
Bottom Bracket
Shimano BB92 PRESS FIT
Chain
KMC X10
Wheels
Rims
WTB I19 TCS rims, SRAM sealed hubs with 15mm QR front and 12mm thru rear
Tires
Schwalbe Racing Ralph 29X2.25, Folding bead
Brakes
Brakes
Shimano SLX, 160mm rotors
Cockpit
Stem
XLC Pro, 31.8mm, 7 degree
Handlebar
XLC Pro, 31.8mm, 700mm width
Grips
Redline Flight flangeless lock-on
Headset
FSA Internal
Seat
Saddle
WTB Volt Race
Seatpost
XLC Pro 27.2mm, 400mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" |
|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.43 mm | 1.41 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm |
| Front Center | 671 mm | 692 mm | 695 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 83 mm | 70 mm | 82 mm |
| Stack | 628 mm | 630 mm | 641 mm |
| Reach | 425 mm | 442 mm | 454 mm |
| Top Tube Length | 611 mm | 632 mm | 647 mm |
| Seat Tube Angle | 73.2 ° | 73.1 ° | 73.1 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1107 mm | 1128 mm | 1131 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm |
| Standover Height | 806 mm | 824 mm | 841 mm |
| Wheels | 29" | 29" | 29" |
Model Overview
D660 is part of the Redline D660 model. There are 2 bikes that carry this model name.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
Redline D660 2014 bike is equipped with the RockShox Reba fork, and has mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The D660 2014 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Redline D660 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
