Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Reba
-
Groupset Avid, FSA -
Suspension Hardtail -
Drivetrain Belt Drive -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full chromoly with slider style Dropouts, Split lugged seat stay
Suspension Fork
RockShox Reba RL 29" Solo Air with 100mm travel
Drivetrain
Shift Levers
Avid DB1 hydrolic levers
Cassette
Gates 22T
Crank
FSA Maximus with Gates carbon drive 46T sprocket
Bottom Bracket
Isis 68mm, 113L
Chain
Gates Center Drive 113 belt length
Wheels
Rims
Alex XD Comp 32H, Double wall, Formula sealed bearing front and rear hubs
Tires
WTB Bronson Comp 29 X 2.2"
Brakes
Brakes
Avid DB1 hydrolic disc brakes with Avid G2CS 160mm rotors
Cockpit
Stem
XLC Pro alloy, 31.8mm
Handlebar
XLC Pro flat top 31.8mm alloy, 700mm width
Grips
Redline Flight flangeless lock-on, 135mm
Seat
Saddle
WTB Volt Race
Seatpost
XLC Pro a27.2 alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" |
|---|---|---|---|
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm |
| Front Center | 642 mm | 661 mm | 681 mm |
| Rake | 39 mm | 39 mm | 39 mm |
| Top Tube Length | 601 mm | 620 mm | 639 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 432 mm | 482 mm | 534 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1077 mm | 1096 mm | 1116 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 779 mm | 806 mm | 839 mm |
| Wheels | 29" | 29" | 29" |
About this model
Monobelt is part of the Redline Monobelt model. There is 1 bike that carries this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
Redline Monobelt 2014 bike is equipped with the RockShox Reba fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Redline Monobelt 2014, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The Monobelt has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
