Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset Ekar -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Parapera Gravel Carbon (not suitable for lowriders)
Drivetrain
Rear Derailleur
Campagnolo Ekar 1x 13
Cassette
EKAR 13-speed 10-44 teeth
Crank
EKAR 13-speed 38T.
Pedals
without
Wheels
Rims
EKAR: CREST 650B with Killhill and Climbhill BLACK
Tires
Schwalbe G-One Allround 622-35
Brakes
Brakes
Depending on the Campa group you choose
Cockpit
Stem
Racing steel Race light Black
Handlebar
Syntace Racelite 420mm
Seat
Saddle
without
Seatpost
Parapera Carbon extralight
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 268 mm | 268 mm | 270 mm | 271 mm | 271 mm |
| Top Tube Length | 530 mm | 550 mm | 565 mm | 585 mm | 625 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 530 mm | 550 mm | 580 mm | 610 mm |
| Head Tube Angle | 72.5 ° | 72 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 140 mm | 150 mm | 165 mm | 185 mm | 230 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 427 mm | 430 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
