Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 160mm -
Travel Rear 155mm -
Fork Fox Factory Float 38
-
Groupset XT -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 170cm
MD
167cm - 177cm
LG
175cm - 188cm
XL
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Revel Rail29 155mm Travel
Suspension Fork
Fox Float 38 Factory Series 160mm GRIP2
Rear Shock
Fox Float X2 Factory Series
Drivetrain
Rear Derailleur
Shimano XT M8100
Shift Levers
Shimano XT M8100
Cassette
Shimano XT M8100 10-51
Crank
Shimano XT M8100 170mm 32t
Bottom Bracket
Shimano XT MT800
Chain
Shimano XT M8100
Wheels
Rims
Crank Bros. Synthesis Enduro Rims, Industry Nine 1/1 Hubs
Tires
Maxxis Minion DHF 29×2.5 EXO TR Front, Maxxis Minion DHR ll 29×2.4 3CT EXO+ TR Rear
Brakes
Brakes
Shimano XT M8120 4-Piston
Cockpit
Stem
Trail 1 Viking 31.8 40mm
Handlebar
Trail 1 Crockett Alloy, 31.8 x 25
Grips
Lizard Skins Charger Evo Grip Black
Headset
Cane Creek 40-series
Seat
Saddle
SM/M: SDG Radar Lux-Alloy L/XL: SDG Bel-Air Lux-Alloy
Seatpost
Crank Brothers Highline 7, SM (31.6mm x 125mm), MD (31.6mm x 150mm), LG (31.6mm x 175mm), XL (31.6 x 200mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.464 mm | 1.405 mm | 1.358 mm | 1.308 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 747 mm | 768 mm | 794 mm | 823 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 123 mm | 123 mm | 123 mm | 123 mm |
| Stack | 625 mm | 628 mm | 637 mm | 646 mm |
| Reach | 427 mm | 447 mm | 469 mm | 494 mm |
| Top Tube Length | 585 mm | 606 mm | 630 mm | 658 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 393.5 mm | 415.5 mm | 453.5 mm | 482.5 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 95 mm | 98 mm | 108 mm | 118 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1181 mm | 1202 mm | 1228 mm | 1257 mm |
| Bottom Bracket Drop | 31 mm | 31 mm | 31 mm | 31 mm |
| Standover Height | 716 mm | 719 mm | 728 mm | 756 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 167 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 177 cm | 188 cm | 200 cm |
