Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 170mm -
Travel Rear 155mm -
Fork Fox Factory Float 38
-
Groupset XT -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 170cm
MD
167cm - 177cm
LG
175cm - 188cm
XL
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Revel Rail29 155mm Travel
Suspension Fork
Fox Float 38 Factory Series 170mm GRIPX2 44
Rear Shock
Fox Float X2 Factory Series
Drivetrain
Rear Derailleur
Shimano XT M8100
Shift Levers
Shimano XT M8100
Cassette
Shimano XT M8100 10-51
Crank
Shimano XT M8100 170mm 32t
Bottom Bracket
Shimano XT MT800
Chain
Shimano XT M8100
Wheels
Rims
Crank Bros. Synthesis Enduro Rims, Industry Nine 1/1 Hubs
Tires
Continental Kryptotal 29" x 2.4" Enduro-F Soft Front, Continental Kryptotal 29" x 2.4" Enduro-R Soft Rear
Brakes
Brakes
Shimano XT M8120 4-Piston
Cockpit
Stem
Trail 1 Viking 31.8 40mm
Handlebar
Trail 1 Crockett Alloy 31.8x25
Grips
Trail 1 Farlow Gap Grip - Black
Headset
Cane Creek 40-series
Seat
Saddle
SDG Saddle Bel Air V3 Lux-Alloy Black
Seatpost
Bike Yoke Revive 2.0, SM (31.6mm x 125mm), MD (31.6mm x 160mm), LG (31.6mm x 185mm), XL/XXL(31.6mm x 213mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.488 mm | 1.428 mm | 1.379 mm | 1.329 mm |
| Bottom Bracket Height | 351 mm | 351 mm | 351 mm | 351 mm |
| Front Center | 758 mm | 779 mm | 805 mm | 835 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 131 mm | 131 mm | 131 mm | 131 mm |
| Stack | 628 mm | 631 mm | 640 mm | 650 |
| Reach | 422 mm | 442 mm | 464 mm | 489 mm |
| Top Tube Length | 585 mm | 606 mm | 630 mm | 658 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 393.5 mm | 415.5 mm | 453.5 mm | 482.5 mm |
| Head Tube Angle | 64.6 ° | 64.6 ° | 64.6 ° | 64.6 ° |
| Head Tube Length | 95 mm | 98 mm | 108 mm | 118 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1193 mm | 1214 mm | 1240 mm | 1270 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm | 28 mm |
| Standover Height | 719 mm | 723 mm | 732 mm | 759 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 167 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 177 cm | 188 cm | 200 cm |
