Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Groupset Force, Force eTap -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
162cm - 171cm
SM
169cm - 176cm
MD
174cm - 181cm
LG
179cm - 186cm
XL
184cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Front Thru-Axle for Carbon Forks
Drivetrain
Shift Levers
Force AXS D2 Shift Lever & Caliper LH
Cassette
XG 1271 D1 XPLR Cassette XDR 10-44T
Crank
Force 1 D2 DUB Wide Crankset 165mm 40T
Brakes
Brakes
Hydraulic Disc
Cockpit
Handlebar
Embossed Black Bar Tape
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.447 mm | 1.463 mm | 1.48 mm | 1.522 mm | 1.542 mm |
| Front Center | 593 mm | 599 mm | 600.7 mm | 615.5 mm | 616 mm |
| Rake | 50 mm | 52 mm | 49 mm | 50 mm | 50 mm |
| Trail | 64 mm | 59 mm | 59 mm | 55 mm | 55 mm |
| Stack | 537 mm | 548.5 mm | 561 mm | 592 mm | 610.7 mm |
| Reach | 371 mm | 375 mm | 379 mm | 389 mm | 396 mm |
| Top Tube Length | 520 mm | 535 mm | 545 mm | 570 mm | 590 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 480 mm | 500 mm | 520 mm | 540 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 130 mm | 140 mm | 150 mm | 180 mm | 200 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1019 mm | 1025 mm | 1025 mm | 1041 mm | 1054 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 162 cm | 169 cm | 174 cm | 179 cm | 184 cm |
| Rider Max Height | 171 cm | 176 cm | 181 cm | 186 cm | 194 cm |
