Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork RST VOLANT
-
Groupset microSHIFT Mezzo -
Suspension Hardtail -
Motor 250W 40Nm hub-drive -
Battery Sportdrive 313wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy
Suspension Fork
RST Volant 63mm Travel
Drivetrain
Rear Derailleur
microSHIFT Mezzo RDM36L 8 Speed
Shift Levers
microSHIFT Mezzo TS39-8R 8 Speed
Cassette
microSHIFT Mezzo CSH082 11-34T 8 Speed
Chain
KMC X8E
Pedals
Resin Metro
Wheels
Front Hub
KT-TC7F / Sportdrive M155
Rear Hub
KT-TC7F / Sportdrive M155
Rims
Alloy J19SZ
Spokes
Steel 14 g
Tires
WTB Riddler 700 x 45c Reflex
Brakes
Brakes
Alhonga AHJ-OD05 Hydraulic Disc Brake
Cockpit
Stem
Alloy 65 mm +9deg
Headset
FSA HS NO.10 1-1/8 inch
Seat
Seatpost
Alloy 27.2 x 350 mm
Motor & Battery
Motor
Sportdrive M155 250W 40Nm
Battery
Sportdrive 313wh
Charger
Sportdrive 2AH
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.436 mm | 1.468 mm | 1.4 mm |
| Front Center | 656 mm | 668 mm | 688 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 86 mm | 86 mm | 86 mm |
| Stack | 580 mm | 599 mm | 599 mm |
| Reach | 404 mm | 408 mm | 428 mm |
| Top Tube Length | 570 mm | 580 mm | 600 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 120 mm | 140 mm | 140 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1105 mm | 1117 mm | 1137 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
