ridgeback X2 Open Frame 2024
2024 E-bike
Estimate price |
2,675$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Fork RST VOLANT -
Groupset microSHIFT Mezzo -
Suspension Hardtail -
Motor Shimano 250W 40Nm mid-drive -
Battery Shimano STEPS BT-E8014 418wh -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy
Suspension Fork
RST Volant 63mm
Drivetrain
Rear Derailleur
microSHIFT Mezzo RDM36L 9 Speed
Shift Levers
microSHIFT Mezzo TS39-9R 9 Speed
Cassette
microSHIFT Mezzo CSH092 11-36T
Chain
KMC X9E
Pedals
Resin Metro
Wheels
Front Hub
KTTC7F / KTTC7R
Rear Hub
KTTC7F / KTTC7R
Spokes
Steel 14 g
Tires
CST Scalato Mondano Reflex 700 x 50c
Brakes
Brakes
ALHONGA AHJ-OD07 Hydraulic Disc Brake
Brake Levers
ALHONGA AHJ-OD07 Hydraulic Disc Brake
Cockpit
Stem
Alloy 65 mm +9deg
Headset
FSA HS NO.10 1-1/8 inch
Seat
Seatpost
Alloy Suspension 27.2 x 300 mm
Motor & Battery
Motor
Shimano STEPS DU-E5000 250w 40nm
Battery
Shimano STEPS BT-E8014 418wh
Charger
Shimano STEPS 2AH
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.616 mm | 1.493 mm |
| Front Center | 655 mm | 677 mm |
| Rake | 45 mm | 45 mm |
| Trail | 86 mm | 68 mm |
| Stack | 627 mm | 600 mm |
| Reach | 388 mm | 402 mm |
| Top Tube Length | 580 mm | 600 mm |
| Seat Tube Angle | 73 ° | 73 ° |
| Seat Tube Length | 431 mm | 483 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 140 mm | 160 mm |
| Chainstay Length | 455 mm | 455 mm |
| Wheelbase | 1102 mm | 1124 mm |
| Bottom Bracket Drop | 65 mm | 65 mm |
| Wheels | 700 | 700 |
