Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
X-Ride Disc, Triple Butted 7005-T6 alloy
Suspension Fork
Oryx Disc TA, Carbon steerer
Drivetrain
Rear Derailleur
Shimano Ultegra 11s
Front Derailleur
Shimano 105 2s
Shift Levers
Shimano ST-R505
Cassette
Shimano 105, 11-28
Crank
FSA Gossamer MegaExo, 46/36
Chain
KMC X11
Wheels
Rims
DT Swiss R24 Spline DB
Tires
Clement MXP 700x33c, Folding
Brakes
Brakes
Shimano BR-RS505 / BR-RS785 Hydraulic Disc, F160/R140
Brake Levers
Shimano ST-R505
Cockpit
Stem
4ZA Stratos
Handlebar
4ZA Stratos
Seat
Saddle
4ZA Stratos Dynamic Comfort
Seatpost
4ZA Stratos, 27,2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.3 mm | 1.34 mm | 1.39 mm | 1.45 mm | 1.47 mm | 1.5 mm |
| Bottom Bracket Height | 291 mm | 287 mm | 284 mm | 282 mm | 280 mm | 280 mm |
| Front Center | 581 mm | 581 mm | 586 mm | mm | 606 mm | 622 mm |
| Rake | 46 mm | 45 mm | 46 mm | mm | 45 mm | 45 mm |
| Trail | 66 mm | 64 mm | 63 mm | mm | 64 mm | 64 mm |
| Stack | 489 mm | 505 mm | 522 mm | 543 mm | 564 mm | 588 mm |
| Reach | 375 mm | 376 mm | 376 mm | 375 mm | 384 mm | 392 mm |
| Top Tube Length | 496 mm | 506 mm | 516 mm | 525 mm | 541 mm | 556 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | ° | 73.5 ° |
| Seat Tube Length | 410 mm | 435 mm | 460 mm | 485 mm | 510 mm | 535 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 89 mm | 100 mm | 115 mm | 135 mm | 155 mm | 180 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 993 mm | 992 mm | 997 mm | mm | 1016 mm | 1032 mm |
| Bottom Bracket Drop | 53 mm | 57 mm | 60 mm | 62 mm | 64 mm | 64 mm |
| Standover Height | 728 mm | 744 mm | 761 mm | 791 mm | 802 mm | 826 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
X-Ride DISC ULTEGRA MIX HDB is part of the Ridley X Ride model. 30 bikes variations carry this model name so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Cyclocross bikes
If you want an acceptable Cyclocross bike you should know that the average price is 2012$. However, this doesn’t mean that if you spend less money on a Cyclocross bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
X-Ride DISC ULTEGRA MIX HDB components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When leaving the production line, the X-Ride DISC ULTEGRA MIX HDB model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Ridley X-Ride DISC ULTEGRA MIX HDB is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
