Riese & Müller Riese & Müller Homage GT rohloff 2024
2024 E-bike
Estimate price |
8,200$
Weight | 30 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Travel Rear 100mm -
Fork Suntour MOBIE
-
Groupset FSA -
Suspension Full -
Motor mid-drive -
Battery Bosch PowerTube 625 Horizontal, 36 V, 13,4 Ah/625Wh; Bosch PowerTube 625 Horizontal, 36 V, 13,4 Ah/625Wh ( 2x )* -
Drivetrain Belt Drive -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
SR Suntour Mobie 34, Air, tapered, 100mm
Rear Shock
Suntour RS-19 190x40
Drivetrain
Shift Levers
Rohloff E14 electronic shifter
Crank
FSA/Riese & Müller, 170 mm
Chain
Gates drive belt CDX
Chain Guide
Riemenschutzring
Pedals
VP R&M Custom
Wheels
Front Hub
Novatec Disc 32H
Rear Hub
Rohloff Speedhub E14, 14-speed, 36H
Rims
Rodi Tryp35 Evo 27,5"
Spokes
Sapim Leader 2,0 mm, Inox, black ( 16x ); Sapim Leader 2,0 mm, Inox, black ( 36x )
Tires
Schwalbe Super Moto-X 62-584 Reflex; Schwalbe Johnny Watts 60-584*
Brakes
Brakes
Magura MT4, disc brake; Magura MT5, disc brake
Cockpit
Stem
Humpert ergotec Barracuda Evo, 90 mm, 20°; Satori R&M Custom, cable integration, adjustable angle, Alu*
Handlebar
Humpert ergotec Ergo XXL, 31,8 mm; Humpert ergotec Trekking, 31,8 mm, Alu*; Satori R&M Custom Komfort, 25,4 mm, Alu*; Satori R&M Custom, 25,4mm, Alu*
Grips
Ergon ergonomic
Headset
Acros Integration X, block lock
Seat
Saddle
Selle Royal New Lookin Male Eco; Selle Royal New Lookin Female Eco*
Seatpost
Satori Trident; Dropper Post X-Fusion Manic 70*
Motor & Battery
Motor
Performance Line CX (Gen4)
Battery
Bosch PowerTube 625 Horizontal, 36 V, 13,4 Ah/625Wh; Bosch PowerTube 625 Horizontal, 36 V, 13,4 Ah/625Wh ( 2x )*
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 54cm | 58cm |
|---|---|---|---|
| Stack Reach Ratio | 1.714 mm | 1.61 mm | 1.5 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm |
| Trail | 89 mm | 89 mm | 89 mm |
| Stack | 660 mm | 660 mm | 660 mm |
| Reach | 385 mm | 410 mm | 440 mm |
| Top Tube Length | 585 mm | 610 mm | 640 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 160 mm | 160 mm | 160 mm |
| Chainstay Length | 505 mm | 505 mm | 505 mm |
| Wheelbase | 1170 mm | 1190 mm | 1220 mm |
| Front Travel | 100 mm | 100 mm | 100 mm |
| Rear Travel | 100 mm | 100 mm | 100 mm |
| Wheels | 650 | 650 | 650 |
