Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
52cm
162cm - 171cm
55cm
169cm - 181cm
59cm
179cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Frameset CR-MO SAE 4130, with Double Butted tubes, TIG welding, removable Silder dropout with integrated chain tensioners
Drivetrain
Cassette
Sturmey Archer 18T
Crank
RIVA – Aluminum 6061 – Crown in Aluminum 7075
Bottom Bracket
Square Tip – Sealed Cartridge – 68mm x 110mm
Chain
KMC KM Z410ARB – Anti Rust Busted
Pedals
Wellgo M-224G
Wheels
Tires
Schwalbe Road Cruiser 700x35C – Green Compound
Brakes
Brakes
Tektro HD-T285 – 160mm Discs – Forged Aluminum Calipers – Non-Corrosive Mineral Oil
Cockpit
Stem
Riva 90mm – Height 40mm
Handlebar
Riva Riser 25.4mm – 520mm
Headset
1-1/8 Sealed Bearings
Seat
Seatpost
Riva 27.2mm x 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 55cm | 59cm |
|---|---|---|---|
| Rake | 40 mm | 40 mm | 40 mm |
| Stack | 520 mm | 550 mm | 590 mm |
| Top Tube Length | 540 mm | 550 mm | 575 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm |
| Standover Height | 770 mm | 850 mm | 950 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 179 cm |
| Rider Max Height | 171 cm | 181 cm | 191 cm |
