Rocky Mountain Slayer Carbon 50 2024

Bike details

Overview

Key information split into simple groups.

Bike summary

Category
- Mountain
- |
- Enduro
Frame Carbon
Travel Front 180mm
Travel Rear 180mm
Fork Fox Performance Float 38
Groupset GX Eagle, Truvativ Stylo
Suspension Full
Drivetrain 1 × 12
Brakes SRAM Code R Hydraulic Disc

Sizing

Recommended size guide.

SM Steep
155cm - 167cm
SM
155cm - 167cm
SM Slack
155cm - 167cm
MD Steep
165cm - 177cm
MD
165cm - 177cm
MD Slack
165cm - 177cm
LG Steep
175cm - 188cm
LG
175cm - 188cm
LG Slack
175cm - 188cm
XL
185cm - 198cm
XL Steep
185cm - 198cm
XL Slack
185cm - 198cm

Parts list

Components

Main components, grouped by system.

Bike components

Frame

Suspension Fork

Fox 38 Float EVOL GRIP Performance Series | 180mm | 44mm Offset

Rear Shock

Drivetrain

Rear Derailleur

SRAM GX Eagle

Shift Levers

SRAM GX Eagle

Cassette

SRAM PG-1230 11-50T

Crank

SRAM Stylo 6K Eagle | 32T | DUB Spindle | Crankarm Length: SM = 165mm Crankarm | MD - XL = 170mm

Bottom Bracket

SRAM BB92 DUB Wide

Chain

SRAM NX Eagle

Wheels

Front Hub

Rocky Mountain SL Sealed Boost 15mm

Rear Hub

Novatec MTB SL Team Boost 148mm

Rims

WTB ST i30 TCS 2.0 Tubeless | 32H / Tubeless Ready - Tape / Valves Incl

Spokes

DT Swiss Champion 2.0

Tires

F: Maxxis Assegai 2.5 WT 3C MaxxGrip DD Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready // Cushcore Trail Tire Inserts | Lightweight | Tire & Rim Protection

Brakes

SRAM Code R 4 Piston | Metal Pads

Cockpit

Stem

Rocky Mountain 35 AM | 5° Rise | All Sizes = 40mm

Handlebar

Grips

ODI Elite Pro Lock On

Headset

Seat

Saddle

WTB Volt Race 142

Seatpost

X Fusion Manic Composite 30.9mm | SM = 150mm | MD = 170mm | LG - XL = 200mm

Fit data

Geometry

Numbers for sizing and ride feel.

Size	SM Steep	SM	SM Slack	MD Steep	MD	MD Slack	LG Steep	LG	LG Slack	XL	XL Steep	XL Slack
Stack Reach Ratio	1.425 mm	1.44 mm	1.469 mm	1.347 mm	1.36 mm	1.384 mm	1.304 mm	1.321 mm	1.346 mm	1.269 mm	1.253 mm	1.292 mm
Front Center	784 mm	784 mm	784 mm	809 mm	809 mm	809 mm	841 mm	842 mm	842 mm	879 mm	878 mm	878 mm
Rake	39 mm	39 mm	39 mm	39 mm	39 mm	38 mm	43 mm	44 mm	45 mm	45 mm	44 mm	44 mm
Trail	145 mm	147 mm	151 mm	145 mm	147 mm	152 mm	140 mm	141 mm	144 mm	140 mm	139 mm	145 mm
Stack	617 mm	619 mm	623 mm	617 mm	619 mm	623 mm	631 mm	634 mm	638 mm	647 mm	644 mm	651 mm
Reach	433 mm	430 mm	424 mm	458 mm	455 mm	450 mm	484 mm	480 mm	474 mm	510 mm	514 mm	504 mm
Top Tube Length	566 mm	567 mm	568 mm	591 mm	592 mm	593 mm	620 mm	621 mm	622 mm	653 mm	653 mm	655 mm
Seat Tube Angle	77.8 °	77.5 °	77 °	77.8 °	77.5 °	77 °	77.8 °	77.5 °	77 °	77.5 °	77.8 °	77 °
Seat Tube Length	380 mm	380 mm	380 mm	410 mm	410 mm	410 mm	440 mm	440 mm	440 mm	470 mm	470 mm	470 mm
Head Tube Angle	63.3 °	63 °	62.5 °	63.3 °	63 °	62.5 °	63.3 °	63 °	62.5 °	63 °	63.3 °	62.5 °
Head Tube Length	100 mm	100 mm	100 mm	100 mm	100 mm	100 mm	110 mm	110 mm	110 mm	125 mm	125 mm	125 mm
Chainstay Length	438 mm	439 mm	440 mm	438 mm	439 mm	440 mm	438 mm	439 mm	440 mm	439 mm	438 mm	440 mm
Wheelbase	1222 mm	1223 mm	1224 mm	1247 mm	1248 mm	1249 mm	1278 mm	1280 mm	1281 mm	1317 mm	1315 mm	1317 mm
Bottom Bracket Drop	5 mm	9 mm	16 mm	5 mm	9 mm	16 mm	19 mm	22 mm	29 mm	22 mm	19 mm	29 mm
Standover Height	824 mm	821 mm	820 mm	824 mm	821 mm	820 mm	827 mm	823 mm	820 mm	823 mm	827 mm	822 mm
Wheels	29"	29"	29"	29"	29"	29"	29"	29"	29"	29"	29"	29"
Rider Min Height	155 cm	155 cm	155 cm	165 cm	165 cm	165 cm	175 cm	175 cm	175 cm	185 cm	185 cm	185 cm
Rider Max Height	167 cm	167 cm	167 cm	177 cm	177 cm	177 cm	188 cm	188 cm	188 cm	198 cm	198 cm	198 cm
