Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset microSHIFT Advent -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rocky Mountain 6061 Alloy | Threaded BB | Zero Stack Tapered Headtube | Dropper Post Compatible
Suspension Fork
Suntour XCM32 DS NLO 120mm
Drivetrain
Rear Derailleur
MicroShift Advent With Clutch
Shift Levers
MicroShift Xpress Plus 9spd
Cassette
MicroShift CS-H093 11-46T
Crank
Rocky Mountain Microdrive 3PC | 30T | 104mm Asymmetrical BCD | Crank Length: XS-SM-MD = 170-mm | LG - XL = 175mm
Bottom Bracket
Sealed Cartridge Bearing
Chain
KMC X9
Wheels
Front Hub
Shimano QC300
Rear Hub
Shimano QC300
Rims
Rocky Mountain TR25 | 32H |
Spokes
2.0 Stainless
Tires
Kenda Amrak 27.5 x 2.4 | Kenda Amrak 27.5 x 2.4 |
Brakes
Brakes
Shimano MT200 2 Piston | Resin Pads
Cockpit
Stem
Rocky Mountain 31.8 XC | 7° Rise | All Sizes = 40mm
Handlebar
Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp
Grips
Rocky Mountain Lock On Ergo
Headset
Rocky Mountain | Loose Ball Bearings | 1-1/8" Reducer Crown Race
Seat
Saddle
Rocky Mountain 148 Steel
Seatpost
Rocky Mountain 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
