Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Recon Silver TK
-
Groupset SLX, Acera -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rocky Mountain 6061 Series Custom Hydroformed Alloy Frame Threaded BB ZeroStack 1-1/8\" Headtube Rack and Fender Mounts
Suspension Fork
RockShox Recon Silver TK 29 Solo Air
Drivetrain
Rear Derailleur
Shimano SLX 9spd
Front Derailleur
Shimano Acera 31.8mm 9spd
Shift Levers
Shimano Deore Rapid Fire 9spd
Cassette
Shimano HG30 11-34 9spd
Crank
Shimano Deore 170-175mm 44/32/22T 9spd
Bottom Bracket
Shimano Deore Hollowtech
Chain
Shimano HG53 9spd
Wheels
Front Hub
Shimano RM66 Disc
Rear Hub
Shimano RM66 Disc
Rims
Wheeltech SX17 By WTB
Spokes
Stainless
Tires
Continental Race King 29\" x 2.2\"
Brakes
Brakes
Shimano BR-M446 Hydraulic Disc 160mm
Brake Levers
Shimano BL-M446
Cockpit
Stem
Rocky Mountain L7 7° x 60-90mm
Handlebar
Rocky Mountain Zero9 Flat Ø31.8mm x 700mm x 9° Sweep
Grips
Rocky Mountain XC Kraton
Headset
Cane Creek Five Series: ZS44mm
Seat
Saddle
Rocky Mountain XC
Seatpost
Rocky Mountain L2B 27.2mm x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 318 mm | 318 mm | 318 mm | 318 mm |
| Front Center | 630 mm | 652 mm | 676 mm | 699 mm |
| Top Tube Length | 564 mm | 586 mm | 609 mm | 632 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 394 mm | 432 mm | 470 mm | 508 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1065 mm | 1087 mm | 1111 mm | 1134 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Trailhead 29 belongs to the Rockymountain Trailhead model. 6 bikes variations carry this model name so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Trailhead 29 components
Fork
The fork installed on this bike is the RockShox Recon Silver TK model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When it comes to wheels, the Trailhead 29 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Trailhead 29 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
