Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Apex XPLR -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes SRAM Apex Mechanical Disc
Sizing
Recommended size guide.
XS High
150cm - 166cm
SM High
164cm - 174cm
SM
164cm - 174cm
MD High
171cm - 181cm
MD
171cm - 181cm
LG High
178cm - 188cm
LG
178cm - 188cm
XL High
185cm - 194cm
XL
185cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
RONDO RUUT G3 ALU
Suspension Fork
RONDO RUUT G3 TWINTIP CARBON
Drivetrain
Rear Derailleur
SRAM APEX XPLR D1
Front Derailleur
-
Shift Levers
SRAM APEX XPLR
Cassette
SRAM XPLR D1 11-44 12 SPEED
Crank
SRAM APEX 42T 165 (XS), 170MM(S), 172.5MM(M,L), 175MM (XL)
Bottom Bracket
PF 86
Chain
CN APEX D1 12S 116LI
Wheels
Front Hub
RONDO SUPERLIGHT SEALED BEARINGS / WTB
Rear Hub
RONDO SUPERLIGHT SEALED BEARINGS / WTB
Rims
RONDO RIM 622-23/WTB SPORTERRA 622-25/584-25
Tires
WTB VULPINE 700C X 45 / WTB VENTURE 650B X 47 (XS)
Brakes
Brakes
SRAM APEX1
Cockpit
Stem
RONDO 70MM(XS, S, M), 90MM(L, XL)
Handlebar
RONDO FLARE 400MM (XS), 420MM(S), 440MM(M,L), 460MM(XL)
Grips
San Marco
Headset
UPPER STACK: IS 52 / 28,6 LOWER STACK: IS 52 / 40 SHIS
Seat
Saddle
SELLE ITALIA MODEL Y
Seatpost
RONDO 350 X 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS High | SM High | SM | MD High | MD | LG High | LG | XL High | XL |
|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.436 mm | 1.401 mm | 1.439 mm | 1.41 mm | 1.448 mm | 1.427 mm | 1.463 mm | 1.452 mm | 1.488 mm |
| Front Center | 584 mm | 608 mm | 601 mm | 627 mm | 619 mm | 652 mm | 644 mm | 670 mm | 662 mm |
| Rake | 55 mm | 55 mm | 45 mm | 55 mm | 45 mm | 55 mm | 45 mm | 55 mm | 45 mm |
| Trail | 55 mm | 54 mm | 69 mm | 51 mm | 67 mm | 50 mm | 66 mm | 50 mm | 67 mm |
| Stack | 527 mm | 542 mm | 547 mm | 567 mm | 572 mm | 595 mm | 600 mm | 620 mm | 625 mm |
| Reach | 367 mm | 387 mm | 380 mm | 402 mm | 395 mm | 417 mm | 410 mm | 427 mm | 420 mm |
| Top Tube Length | 522 mm | 545 mm | 547 mm | 569 mm | 570 mm | 592 mm | 594 mm | 610 mm | 611 mm |
| Seat Tube Angle | 73.7 ° | 73.7 ° | 73 ° | 73.7 ° | 73 ° | 73.7 ° | 73 ° | 73.7 ° | 73 ° |
| Seat Tube Length | 465 mm | 485 mm | 485 mm | 510 mm | 510 mm | 540 mm | 540 mm | 570 mm | 570 mm |
| Head Tube Angle | 71.2 ° | 71.2 ° | 70.5 ° | 71.7 ° | 71 ° | 71.7 ° | 71 ° | 71.7 ° | 71 ° |
| Head Tube Length | 110 mm | 120 mm | 120 mm | 145 mm | 145 mm | 175 mm | 175 mm | 200 mm | 200 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 994 mm | 1017 mm | 1011 mm | 1036 mm | 1029 mm | 1061 mm | 1054 mm | 1079 mm | 1072 mm |
| Bottom Bracket Drop | 70 mm | 75 mm | 70 mm | 75 mm | 70 mm | 75 mm | 70 mm | 75 mm | 70 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 150 cm | 164 cm | 164 cm | 171 cm | 171 cm | 178 cm | 178 cm | 185 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 174 cm | 181 cm | 181 cm | 188 cm | 188 cm | 194 cm | 194 cm |
