Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Apex -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
171cm - 181cm
LG
178cm - 188cm
XL
185cm - 194cm
XS High
150cm - 166cm
SM High
164cm - 174cm
MD High
171cm - 181cm
LG High
178cm - 188cm
XL High
185cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
RUUT 2.0 CUSTOM FORMED AL6061-T6
Suspension Fork
TWINTIP 2.0 CARBON
Drivetrain
Rear Derailleur
SRAM APEX 1
Front Derailleur
'-
Shift Levers
SRAM APEX 1
Cassette
11-42 11 SPEED
Crank
FSA OMEGA EXO 42T 160MM (XS), 170MM(S), 172.5MM(M,L), 175MM (XL)
Bottom Bracket
PF 86/FSA
Chain
SRAM PC1130
Wheels
Front Hub
RONDO SUPERLIGHT SEALED BEARINGS
Rear Hub
RONDO SUPERLIGHT SEALED BEARINGS
Rims
RONDO ALUMINIUM 622-21/584-21(XS)
Tires
WTB NANO 700C X 40/SCHWALBE G-ONE BITE 650B X 40 (XS)
Brakes
Brakes
PRO hydro-mechanical
Cockpit
Stem
RONDO 60MM(XS) 80MM(S), 90MM(M,L), 110MM(XL)
Handlebar
RONDO FLARE 400MM (XS), 420MM(S), 440MM(M,L), 460MM(XL)
Grips
San Marco
Headset
UPPER STACK: IS 42 / 28,6 LOWER STACK: IS 52 / 40 SHIS
Seat
Saddle
SELLE ITALIA MODEL X
Seatpost
RONDO 350 X 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | XS High | SM High | MD High | LG High | XL High |
|---|---|---|---|---|---|---|---|---|
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 171 cm | 178 cm | 185 cm | 150 cm | 164 cm | 171 cm | 178 cm | 185 cm |
| Rider Max Height | 181 cm | 188 cm | 194 cm | 166 cm | 174 cm | 181 cm | 188 cm | 194 cm |
