Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Force -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM High
165cm - 174cm
SM Low
165cm - 174cm
MD High
171cm - 181cm
MD Low
171cm - 181cm
LG High
178cm - 188cm
LG Low
178cm - 188cm
XL High
185cm - 194cm
XL Low
185cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
RUUT FLEX DESIGN EPS CARBON
Suspension Fork
TWINTIP 2.0 CARBON
Drivetrain
Rear Derailleur
SRAM FORCE 1
Front Derailleur
'-
Shift Levers
SRAM FORCE 1
Cassette
SRAM XG1175 10-42 11 SPEED
Crank
SRAM FORCE 1 DUB X-SYNC 42T 170MM(S), 172.5MM(M,L), 175MM (XL)
Bottom Bracket
EVO 386/SRAM DUB
Chain
SRAM PC1130
Wheels
Front Hub
RONDO X HUNT STRAIGHT PULL
Rear Hub
RONDO X HUNT STRAIGHT PULL
Rims
RONDO X HUNT GRAVEL X-WIDE ALUMINIUM
Tires
VITTORIA TERRENO DRY 700C X 40
Brakes
Brakes
SRAM FORCE HYDRAULIC BRAKES
Cockpit
Stem
RONDO 80MM(S), 90MM(M,L), 110MM(XL)
Handlebar
SPANK WING 12 420MM(S), 440MM(M,L), 460MM(XL)
Grips
VELO COMFORT TAPE
Headset
UPPER STACK: IS 42 / 28,6 LOWER STACK: IS 52 / 40 SHIS
Seat
Saddle
SELLE SAN MARCO SHORTFIT
Seatpost
RONDO CARBON 350 X 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.394 mm | 1.433 mm | 1.418 mm | 1.461 mm | 1.455 mm | 1.497 mm | 1.48 mm | 1.515 mm |
| Bottom Bracket Height | 275 mm | 279 mm | 275 mm | 279 mm | 275 mm | 279 mm | 275 mm | 279 mm |
| Front Center | 601 mm | 591 mm | 606 mm | 597 mm | 625 mm | 615 mm | 638 mm | 630 mm |
| Rake | 55 mm | 45 mm | 55 mm | 45 mm | 55 mm | 45 mm | 55 mm | 45 mm |
| Trail | 57 mm | 76 mm | 53 mm | 69 mm | 53 mm | 70 mm | 53 mm | 70 mm |
| Stack | 531 mm | 536 mm | 553 mm | 558 mm | 582 mm | 587 mm | 601 mm | 606 mm |
| Reach | 381 mm | 374 mm | 390 mm | 382 mm | 400 mm | 392 mm | 406 mm | 400 mm |
| Top Tube Length | 536 mm | 538 mm | 551 mm | 553 mm | 569 mm | 571 mm | 579 mm | 585 mm |
| Seat Tube Angle | 73.8 ° | 73 ° | 73.8 ° | 73 ° | 73.8 ° | 73 ° | 73.8 ° | 73 ° |
| Seat Tube Length | 495 mm | 495 mm | 530 mm | 530 mm | 560 mm | 560 mm | 590 mm | 590 mm |
| Head Tube Angle | 71.3 ° | 70.5 ° | 72.3 ° | 71.5 ° | 72.3 ° | 71.5 ° | 72.3 ° | 71.5 ° |
| Head Tube Length | 110 mm | 110 mm | 130 mm | 130 mm | 160 mm | 160 mm | 180 mm | 180 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1010 mm | 1001 mm | 1015 mm | 1007 mm | 1034 mm | 1025 mm | 1047 mm | 1040 mm |
| Bottom Bracket Drop | 74 mm | 70 mm | 74 mm | 70 mm | 74 mm | 70 mm | 73 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 165 cm | 165 cm | 171 cm | 171 cm | 178 cm | 178 cm | 185 cm | 185 cm |
| Rider Max Height | 174 cm | 174 cm | 181 cm | 181 cm | 188 cm | 188 cm | 194 cm | 194 cm |
