Rose Backroad AL PLUS Apex XPLR 1×12 2024
2024 E-bike
Estimate price |
4,405$
Weight | 13.4 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Apex XPLR -
Suspension Rigid -
Motor MAHLE hub-drive -
Battery 250 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ROSE Backroad PLUS AL, 12x142, frame weight for M approx. 2060g, aluminum, Pressfit BB86 Sandy Taco M
Suspension Fork
ROSE Backroad AL+, carbon, 12x100TA, fork weight 430 g Sandy Taco
Drivetrain
Rear Derailleur
SRAM Apex XPLR black
Shift Levers
Front: SRAM Apex black, rear: SRAM Apex black
Crank
SRAM Apex 1 Wide DUB 40T. STEEL, black 172.5mm
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM Apex 12-speed, gray 116gl.
Pedals
ROSE VP-836 black
Wheels
Rims
ROSE G Thirty+, black 32 holes, ROSE G Thirty Plus black 28 holes
Tires
WTB Raddler TCS, black/tan 700x44C
Brakes
Brakes
Front: SRAM Apex black, rear: SRAM Apex black
Cockpit
Stem
ROSE ALR, black sand 90mm
Handlebar
Ritchey Road COMP Venture Max, black 42cm
Seat
Saddle
Rose Edition by Selle Italia, black
Seatpost
Ritchey WTB, 350mm, black 27.2mm
Motor & Battery
Motor
Mahle X35
Battery
250 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.506 mm | 1.53 mm | 1.582 mm | 1.573 mm | 1.587 mm |
| Bottom Bracket Height | 284 mm | 281 mm | 277 mm | 273 mm | 273 mm |
| Front Center | 590 mm | 603 mm | 613 mm | 629 mm | 643 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 77 mm | 74 mm | 70 mm | 67 mm | 67 mm |
| Stack | 544.5 mm | 569 mm | 598 mm | 619 mm | 637 mm |
| Reach | 361.5 mm | 372 mm | 378 mm | 393.5 mm | 401.5 mm |
| Top Tube Length | 515 mm | 535 mm | 555 mm | 577 mm | 590 mm |
| Seat Tube Angle | 74.25 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 508 mm | 535 mm | 560 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 125 mm | 146 mm | 170 mm | 186 mm | 205 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1011 mm | 1023 mm | 1032 mm | 1048 mm | 1062 mm |
| Bottom Bracket Drop | 65 mm | 68 mm | 72 mm | 76 mm | 76 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
