Rose Backroad AL Plus EQ 2025
2025 E-bike
Estimate price |
4,923$
Weight | 15.9 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset CUES -
Suspension Rigid -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Backroad AL Plus, warm grey XS
Suspension Fork
Backroad AL Plus, Carbon, warm grey
Drivetrain
Rear Derailleur
Shimano CUES, RD-U6000 GS
Cassette
Shimano CUES, CS-LG400-11, 11-50
Crank
Shimano Cues FC-U6040 40Z, 170mm
Chain
Shimano CN-HG601 118gl.
Pedals
ROSE VP-836, schwarz
Brakes
Brakes
Shimano CUES, ST-U6030, Shimano Cues BL-U6030, 160mm,
Cockpit
Stem
ROSE ALR, schwarz sand 80mm
Handlebar
Ritchey Road COMP Butano II, 40cm
Seat
Saddle
Sella Italia Model X Superflow, schwarz
Seatpost
Ritchey WTB, 350mm, schwarz 27,2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.506 mm | 1.53 mm | 1.582 mm | 1.573 mm | 1.587 mm |
| Front Center | 993 mm | mm | mm | mm | mm |
| Stack | 544.5 mm | 569 mm | 598 mm | 619 mm | 637 mm |
| Reach | 361.5 mm | 372 mm | 378 mm | 393.5 mm | 401.5 mm |
| Top Tube Length | 515 mm | 535 mm | 555 mm | 577 mm | 590 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 125 mm | 146 mm | 170 mm | 186 mm | 205 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1011 mm | 1023 mm | 1032 mm | 1048 mm | 1062 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
