Rose Backroad EKAR 2025
2025 Road
Estimate price |
5,234$
Weight | 8.2 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Ekar -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Campagnolo Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ROSE BACKROAD, Carbon dusty purple 50cm
Suspension Fork
ROSE BACKROAD Carbon dusty purple
Drivetrain
Rear Derailleur
Campagnolo EKAR 1x13
Cassette
Campagnolo EKAR 13 speed, 9-42
Crank
Campagnolo EKAR 13s KRG, 170mm, 40 Teeth
Chain
Campagnolo EKAR, 118 L
Pedals
Pedals are not included and must be ordered separately
Wheels
Tires
Continental Terra Speed ProTection, black 40-622
Brakes
Brakes
Campagnolo AFS, Ø160mm
Cockpit
Stem
ROSE Square, anodized black 70mm
Handlebar
Ritchey WCS Butano, blatte 40cm
Seat
Saddle
Fizik Vento Argo X5, 140 mm
Seatpost
ROSE, 8 mm offset 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 53cm | 55cm | 57cm | 59cm | 62cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.445 mm | 1.461 mm | 1.477 mm | 1.484 mm | 1.488 mm | 1.494 mm |
| Bottom Bracket Height | 273 mm | 273 mm | 273 mm | 273 mm | 273 mm | 273 mm |
| Front Center | 585 mm | 597 mm | 606 mm | 617 mm | 628 mm | 649 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 69 mm | 69 mm | 67 mm | 67 mm | 64 mm | 63 mm |
| Stack | 536 mm | 555 mm | 570 mm | 586 mm | 601 mm | 623 mm |
| Reach | 371 mm | 380 mm | 386 mm | 395 mm | 404 mm | 417 mm |
| Top Tube Length | 515 mm | 534 mm | 550 mm | 568 mm | 582 mm | 602 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 500 mm | 520 mm | 540 mm | 575 mm |
| Head Tube Angle | 71 ° | 71.25 ° | 71.5 ° | 71.75 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 120 mm | 135 mm | 150 mm | 165 mm | 188 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1000 mm | 1012 mm | 1021 mm | 1039 mm | 1051 mm | 1072 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 76 mm | 76 mm | 76 mm | 76 mm |
| Standover Height | 757 mm | 782 mm | 799 mm | 816 mm | 834 mm | 862 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
