Rose Black Lava 3 MidStep 2025
2025 Urban
Estimate price |
4,536$
Weight | 16.1 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Drivetrain Belt Drive -
Brakes Shimano XT Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ROSE BLACK LAVA Trekking, aluminium, internal cable routing, Excenter, BSA68, matt black YS 728 / reflective decal 17"
Drivetrain
Crank
Miranda Delta, 55Z, black 170mm
Bottom Bracket
BSA, 68mm, threaded
Chain
Gabtes carbon belt, black 122T
Pedals
ROSE VP-836, black
Wheels
Rims
Newmen Performance 25, 29"
Tires
Schwalbe Marathon Efficiency Perf, black 50-622
Brakes
Brakes
VR: Shimano XT BL-T8100 / BR-M8100, 1000mm, HR: Shimano XT BL-T8100 / BR-M8100, 1700mm
Cockpit
Handlebar
Rose Carbon Flatbar 680x80mm
Grips
ergotec Ambition, black Ø22mm
Seat
Saddle
Article: 2723440
Seatpost
ROSE RC-170, matt carbon 30,9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" | 23" |
|---|---|---|---|---|
| Front Center | 641.5 mm | 646.5 mm | 651.5 mm | 656.5 mm |
| Top Tube Length | 570 mm | 580 mm | 590 mm | 600 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 432 mm | 483 mm | 533 mm | 584 mm |
| Head Tube Angle | 69 ° | 69.5 ° | 70 ° | 70.5 ° |
| Head Tube Length | 165 mm | 175 mm | 185 mm | 195 mm |
| Chainstay Length | 459 mm | 459 mm | 459 mm | 459 mm |
| Wheelbase | 1093 mm | 1099 mm | 1104 mm | 1109 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 |
