Rose BLACK LAVA TR 3 2023
2023 Urban
Estimate price |
2,293$
Weight | 15.2 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork RockShox Paragon Gold RL -
Groupset CUES -
Suspension Hardtail -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ROSE BLACK LAVA TR, HighStep, YS728 matt black 19"
Suspension Fork
Rock Shox Paragon Gold RL, Solo Air black matt
Drivetrain
Rear Derailleur
Shimano CUES, RD-U8020, 10/11 Speed
Front Derailleur
Shimano CUES, FD-U8010-L, 2-10/11, 34,9mm
Shift Levers
Shimano CUES, SL-U8000-11R, 11 Speed, Shimano CUES, SL-U8000-L, Double
Cassette
Shimano CUES, CS-LG700-11, 11-46
Crank
Shimano CUES RD-U8000, 2 fach, 46-32T, 170mm
Chain
Shimano CN-HG601-11 120gl.
Pedals
ROSE VP-836 black
Wheels
Rims
ROSE R Thirty Disc 28"
Tires
Continental Contact, black/black/refl. 700x42C
Brakes
Brakes
Shimano CUES,BL-U8000(L),BR-U8020(F), black 900mm, Shimano CUES,BL-U8000(R),BR-U8020(R), black 1800mm
Cockpit
Stem
ROSE Race Attack UR-100 +-7° black 90mm
Handlebar
ergotec Low Riser Bar, black sand Ø31,8mm
Grips
ergotec Active Flex, black 130mm
Seat
Saddle
Terry Fly Exera Gel
Seatpost
ROSE Race Attack SP-63 XL 350mm, black/matt 30,9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 19" | 21" | 23" | 25" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.629 mm | 1.637 mm | 1.644 mm | 1.658 mm |
| Stack | 622 mm | 638.4 mm | 654.3 mm | 671.2 mm |
| Reach | 381.8 mm | 389.9 mm | 398 mm | 404.8 mm |
| Top Tube Length | 572 mm | 585 mm | 598 mm | 610 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 473 mm | 523 mm | 574 mm | 625 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 140 mm | 155 mm | 172 mm | 190 mm |
| Wheelbase | 1089 mm | 1097 mm | 1111 mm | 1124 mm |
| Wheels | 700 | 700 | 700 | 700 |
