Rose Black Lava TR 3 MidStep 2024
2024 Urban
Estimate price |
2,326$
Weight | 15.3 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork RockShox Paragon Gold RL -
Groupset CUES -
Suspension Hardtail -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ROSE BLACK LAVA TR, MidStep, YS728 matt black 17"
Suspension Fork
Rock Shox Paragon Gold RL, Solo Air black matt
Drivetrain
Rear Derailleur
Shimano CUES, RD-U8020, 10/11 Speed
Front Derailleur
Shimano CUES, FD-U8010-L, 2-10/11, 34,9mm
Shift Levers
Shimano CUES, SL-U8000-11R, 11 Speed, Shimano CUES, SL-U8000-L, Double
Cassette
Shimano CUES, CS-LG700-11, 11-46
Crank
Shimano CUES RD-U8000, 2 fach, 46-32T, 170mm
Chain
Shimano CN-HG601-11 120gl.
Pedals
ROSE VP-836 black
Wheels
Rims
ROSE R Thirty Disc 28"
Tires
Continental Contact, black/black/refl. 700x42C
Brakes
Brakes
Shimano CUES,BL-U8000(L),BR-U8020(F), black 900mm, Shimano CUES,BL-U8000(R),BR-U8020(R), black 1800mm
Cockpit
Stem
ROSE Race Attack UR-100 +-7° black 90mm
Handlebar
ergotec Ladytown, black sand 31,8mm
Grips
ergotec Active Flex, black 130mm
Seat
Saddle
Terry Butterfly Exera,
Seatpost
ROSE Race Attack SP-63 XL 350mm, black/matt 30,9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" |
|---|---|---|---|
| Stack Reach Ratio | 1.616 mm | 1.629 mm | 1.637 mm |
| Stack | 605.8 mm | 622 mm | 638.4 mm |
| Reach | 374.8 mm | 381.8 mm | 389.9 mm |
| Top Tube Length | 402 mm | 453 mm | 503 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 417 mm | 468 mm | 519 mm |
| Head Tube Angle | 69 ° | 69.5 ° | 70 ° |
| Head Tube Length | 125 mm | 140 mm | 155 mm |
| Wheelbase | 1081 mm | 1089 mm | 1097 mm |
| Wheels | 700 | 700 | 700 |
