Rose Bonero Plus 1 2024
2024 E-bike
Estimate price |
5,723$
Weight | 16.9 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 170mm -
Groupset Deore -
Suspension Hardtail -
Battery 360Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ROSE Bonero Plus + Carbon, Splatter Gray M
Drivetrain
Rear Derailleur
Shimano Deore, RD-M6100
Shift Levers
Shimano Deore. SL-M6100-IR, 12x 12x
Crank
e*thirteen Helix Core e*spec, black 165mm, E13 Direct Mount Ring Steel HPR50 black 34 Z.
Chain
Shimano Deore CN-M6100, Quick Link, 12-speed, 122gl.
Wheels
Rims
Newmen Performance base 29" 12x148 29", Newmen Performance 30 base 29" 15x110 29"
Tires
Schwalbe WICKED WILL Evo Super Trail SpeedGrip black 29''x2,4, Schwalbe NOBBY NIC Evo, Super Trail soft black 29''x2,4
Brakes
Brakes
Hydraulic Disc
Cockpit
Handlebar
E13 Base 800mm 35mm Rise black 800x35mm
Seat
Saddle
Rose Edition by Selle Italia, black
Seatpost
e*thirteen Vario Infinite Dropper Post, stealth black, aluminum 31.6mm/490-520mm/150-180mm stroke (180mm preset)
Motor & Battery
Battery
360Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.206 mm | 1.21 mm | 1.235 mm | 1.23 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 746 mm | 775 mm | 813 mm | 851 mm |
| Stack | 762 mm | 766 mm | 798 mm | 817 mm |
| Reach | 632 mm | 633 mm | 646 mm | 664 mm |
| Top Tube Length | 582 mm | 611 mm | 644 mm | 678 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 430 mm | 460 mm | 500 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 100 mm | 115 mm | 135 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1186 mm | 1215 mm | 1253 mm | 1291 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Front Travel | 162 mm | 170 mm | 180 mm | 190 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
