Rose Root Miller 4 2025
2025 Mountain
Estimate price |
5,816$
Weight | 15.8 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 160mm -
Fork RockShox Lyrik Ultimate Flight Attendant
-
Groupset X0 Eagle Transmission, Eagle AXS -
Suspension Full, Electronic -
Drivetrain 1 × 12 Electronic -
Brakes SRAM Code Silver Stealth Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
Rock Shox Lyrik Ultimate Flight Attendant, green 29" Boost, 160mm, 44mm Offset
Rear Shock
Rock Shox Super Deluxe Ultimate Flight Attendant, black Body 20x8
Drivetrain
Rear Derailleur
SRAM X0 T-TYPE AXS, black
Shift Levers
SRAM Controller AXS POD RIGHT BRIDGE black
Cassette
SRAM GX, XS1275 T-Type, Eagle Transmission, 10-52 10-52
Crank
SRAM Powermeter X0 Eagle AXS Transmission 32T, black 170mm, 32 Teeth
Chain
SRAM GX Transmission Flattop, 118 L
Pedals
delivered without pedals
Wheels
Rims
Newmen Beskar Base, 29", Newmen Beskar Strong, 29"
Tires
R: Goodyear Newton Trail Tubless Complete, black 29x2.4, F: Goodyear Newton MTF Trail Tubeless, black 29x2.5
Brakes
Brakes
SRAM Code Silver Stealth, anodized black
Cockpit
Handlebar
E13 Rose Carbon 35mm, black 780mm
Grips
ERGON GA2, black
Seat
Saddle
Rose Edition by Selle Italia, black
Seatpost
e*thirteen Vario Infinite Dropper Post, stealth black, aluminium 31,6mm/430-460mm/120-150mm Hub (150mm voreingestellt)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.402 mm | 1.335 mm | 1.285 mm | 1.241 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 769 mm | 796 mm | 825 mm | 854 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 133 mm | 133 mm | 133 mm | 134 mm |
| Stack | 610 mm | 614 mm | 623 mm | 633 mm |
| Reach | 435 mm | 460 mm | 485 mm | 510 mm |
| Top Tube Length | 581 mm | 608 mm | 637 mm | 665 mm |
| Seat Tube Angle | 76.6 ° | 76.5 ° | 76.3 ° | 76.2 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1210 mm | 1237 mm | 1266 mm | 1295 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm | 28 mm |
| Standover Height | 734 mm | 756 mm | 759 mm | 763 mm |
| Front Travel | 160 mm | 160 mm | 160 mm | 160 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
