Rose Root Miller Plus 3 2025
2025 E-bike
Estimate price |
5,571$
Weight | 23 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 150mm -
Fork RockShox ZEB Select+
-
Groupset XT -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Drivetrain 1 × 12 -
Brakes Shimano SLX Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon
Suspension Fork
Rock Shox ZEB Select+ Charger 3 RC2, black 29" Boost, 150mm, 44mm Offset
Rear Shock
Rock Shox Super Deluxe Slelect+ RT Body 25x8
Drivetrain
Rear Derailleur
Shimano XT, RD-M8100, XT, SGS, 12-fach
Shift Levers
Shimano Deore XT, SL-M8100, 12-fach, 12-fach
Cassette
Shimano SLX, CS-M7100-12, 12-fach, 10-51
Crank
e*thirteen, e*spec Plus Alu Crank, 165mm, 165mm, e*thirteen, e*spec Base DM Chainring, 36Z. Stahl, 36 Z.
Chain
Shimano SLX, CN-M7100, 12-fach mit Quick-Link, 122gl.
Wheels
Tires
Maxxis Assegai, WT, EXO+ TR, Maxx-Grip, schwarz 29x2,5, Maxxis Minion DHR II, WT, EXO+, TR, 3C Maxx Terra, schwarz 27,5x2,6, 650B
Brakes
Brakes
Shimano SLX, 4 Kolben, BL-M7100, BR-M7120, schwarz 900mm, Shimano SLX, 4 Kolben, BL-M7100, BR-M7120, schwarz 1700mm
Cockpit
Stem
Reverse E-Black-ONE Enduro, 50mm, schwarz/grau Ø35mm
Handlebar
Reverse E-Element, Ø35, Rise 25mm, black/grey 770mm
Grips
ERGON GA2, schwarz
Seat
Saddle
Selle italia X-Land E-Bike, black/dark grey
Seatpost
e*thirteen Vario Infinite Dropper Post, stealth black, Aluminium 31,6mm/490-520mm/150-180mm Hub (180mm voreingestellt)
Motor & Battery
Motor
BOSCH Performance Line CX
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.484 mm | 1.418 mm | 1.353 mm | 1.289 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Front Center | 727 mm | 754 mm | 781 mm | 815 mm |
| Rake | 37 mm | 35 mm | 35 mm | 35 mm |
| Trail | 118 mm | 120 mm | 120 mm | 120 mm |
| Stack | 616 mm | 624 mm | 629 mm | 638 mm |
| Reach | 415 mm | 440 mm | 465 mm | 495 mm |
| Top Tube Length | 564 mm | 590 mm | 616 mm | 648 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm | 120 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1171 mm | 1198 mm | 1225 mm | 1259 mm |
| Bottom Bracket Drop | 5 mm | 5 mm | 5 mm | 5 mm |
| Standover Height | 757 mm | 764 mm | 773 mm | 779 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
