Rose Thrill Hill 1 2024
2024 Mountain
Estimate price |
3,140$
Weight | 12.7 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 120mm -
Travel Rear 100mm -
Fork RockShox Reba
-
Groupset SX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 174cm
MD
171cm - 185cm
LG
182cm - 195cm
XL
192cm - 205cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
THRILL HILL, Carbon, Boost, Pressfit 30, approx. 1800g Matt Black/Piano Black M
Suspension Fork
Rock Shox Reba, Motion Control, RL Remote, SoloAir, Boost, 29", 120mm, 51mm Offset
Rear Shock
Rock Shox SID LUXE SELECT+ RLR, SOLO AIR 1 TOKEN black 190mm
Drivetrain
Rear Derailleur
SRAM RD SX Eagle AL, black
Shift Levers
SRAM SX Eagle Trigger, 12-speed, black
Cassette
SRAM Eagle, 12-speed, black 11-50
Crank
SRAM SX Eagle, DUB, Boost, 32T, 175mm
Bottom Bracket
PF30, press-fit
Chain
SRAM SX Eagle, 12-speed, grey 116 L
Pedals
delivered without pedals
Wheels
Rims
front: Sunringlé Düroc 30 Comp, 15x110mm, black 29", rear: Sunringlé Düroc 30 Comp, 12x148mm, black 29"
Tires
Continental Cross King ShieldWallSystem, black 29x2.2
Brakes
Brakes
rear: Shimano, BL-M4100, 900mm, Shimano BL-M4100 1800mm
Cockpit
Stem
Reverse LEAD, Ø31.8, black 75mm
Handlebar
Reverse, H-Bar, 740mm, black Ø31,8mm
Grips
ERGON GA2, black
Seat
Saddle
Rose Edition by Selle Italia, black
Seatpost
e*thirteen, Vario Infinite Dropper Post, incl. Compact Remote, stealth black, aluminium 31,6mm/430-460mm/120-150mm Hub (150mm voreingestellt)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.446 mm | 1.379 mm | 1.314 mm | 1.273 mm |
| Bottom Bracket Height | 330.5 mm | 330.5 mm | 330.5 mm | 330.5 mm |
| Front Center | 673 mm | 693 mm | 725 mm | 751 mm |
| Rake | 23 mm | 23 mm | 24 mm | 24 mm |
| Trail | 115 mm | 115 mm | 114 mm | 114 mm |
| Stack | 593 mm | 593 mm | 602 mm | 611 mm |
| Reach | 410 mm | 430 mm | 458 mm | 480 mm |
| Top Tube Length | 574 mm | 594 mm | 625 mm | 650 |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 422 mm | 450 mm | 480 mm | 510 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1109 mm | 1129 mm | 1161 mm | 1187 mm |
| Bottom Bracket Drop | -42 mm | -42 mm | -42 mm | -42 mm |
| Standover Height | 778 mm | 778 mm | 781 mm | 782 mm |
| Front Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Rear Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 171 cm | 182 cm | 192 cm |
| Rider Max Height | 174 cm | 185 cm | 195 cm | 205 cm |
