Rose Xtra Watt Evo Plus 1 LowStep 2024
2024 E-bike
Estimate price |
4,405$
Weight | 26.5 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset XT, SLX -
Motor Bosch 600W 63Nm mid-drive -
Battery BOSCH PowerTube (500 Wh) -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ROSE derailleur hanger
Drivetrain
Rear Derailleur
Shimano Deore XT, SGS RD-M8000, 11-speed, black
Shift Levers
Shimano SLX, SL-M7000-R, 11-speed,
Crank
FSA 42 teeth incl. protective ring 42 teeth.
Chain
Shimano CN-E8000-11, 138 links, HG-X 11-speed 138gl.
Pedals
ROSE VP-836, black
Wheels
Rims
Newmen Performance 25, 29"
Tires
Continental Pure Contact, foldable, praphit-reflex black/black. 47-622
Brakes
Brakes
Front: Shimano BL-MT200, black, Rear: Shimano BL-MT200, black
Cockpit
Stem
Rose Race Attack UR-100 +-7°, black 90mm
Handlebar
Ergotec bracket Ladytown, 30°, Level 5, GW620, GL178, GH15 black sand 31.8mm
Seat
Saddle
Terry Fisio Women
Seatpost
ROSE Race Attack SP-63 XL 350mm, black/matt 31.6mm
Motor & Battery
Motor
Bosch Performance Line Generation 3, black
Battery
BOSCH PowerTube (500 Wh)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" | 23" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.634 mm | 1.604 mm | 1.591 mm | 1.65 mm |
| Bottom Bracket Height | 302.5 mm | 302.5 mm | 302.5 mm | 302.5 mm |
| Front Center | 670 mm | 674 mm | 673 mm | 681 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 88 mm | 85 mm | 81 mm | 81 mm |
| Stack | 647 mm | 649.5 mm | 651.5 mm | 675 mm |
| Reach | 396 mm | 405 mm | 409.5 mm | 409 mm |
| Top Tube Length | 600 mm | 610 mm | 615 mm | 622 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 432 mm | 483 mm | 533 mm | 584 mm |
| Head Tube Angle | 69 ° | 69.5 ° | 70 ° | 70 ° |
| Head Tube Length | 175 mm | 175 mm | 175 mm | 200 mm |
| Chainstay Length | 487 mm | 487 mm | 487 mm | 487 mm |
| Wheelbase | 1151 mm | 1155 mm | 1154 mm | 1162 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 |
