rossignol E-Track 29 Deore 12 E-Mountain Bike 2024
2024 E-bike
Estimate price |
4,226$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Fork RockShox Recon Silver RL -
Groupset Deore -
Suspension Hardtail -
Motor Shimano 600W 85Nm mid-drive -
Battery Shimano STEPS E8036 (630 Wh)S size model with 504Wh battery -
Brakes Shimano Alivio Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rossignol Hardtail Electric
Suspension Fork
Rock Shox RECON SILVER RL 100MM
Rear Shock
-
Drivetrain
Rear Derailleur
Shimano Deore M6100, SGS
Shift Levers
Shimano Deore M6100
Cassette
Shimano Deore M6100, 10-51T
Crank
-
Chain
Shimano Deore M6100
Chain Guide
GW 1x flip guide
Pedals
Flat Pedals
Wheels
Front Hub
SHIMANO TC500
Rear Hub
SHIMANO TC500
Rims
Alex rim DP30-F 29
Tires
MAXXIS 29 x2.4 Ardent EXO
Brakes
Brakes
Shimano MT-200, 2-piston
Brake Levers
Shimano MT-200, 2-piston
Cockpit
Stem
ROSSIGNOL MTB stem 31,8mm
Handlebar
ROSSIGNOL MTB handlebar 780mm
Grips
Rossignol diamond grip lock-on
Headset
ZS (ZS44/28.6-ZS56/40) / (NO.57)
Seat
Saddle
VELO MTB SADDLE
Seatpost
KS EDGE I
Motor & Battery
Motor
Shimano STEPS MTB EP6
Battery
Shimano STEPS E8036 (630 Wh)S size model with 504Wh battery
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.482 mm | 1.417 mm |
| Front Center | 717 mm | 752 mm | 772 mm |
| Rake | 50 mm | 50 mm | 51 mm |
| Trail | 92 mm | 92 mm | 90 mm |
| Stack | 649 mm | 649 mm | 649 mm |
| Reach | 403 mm | 438 mm | 458 mm |
| Top Tube Length | 590 mm | 614 mm | 627 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 430 mm | 470 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1160 mm | 1195 mm | 1216 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
