rossignol Ebike E-Track 29 Deore 12 2024
2024 E-bike
Estimate price |
4,536$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Fork RockShox Recon Silver RL -
Groupset Deore -
Suspension Hardtail -
Motor Shimano 600W 85Nm mid-drive -
Battery Shimano STEPS E8036 (630 Wh) S size model with 504Wh battery -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rossignol Hardtail Electric
Suspension Fork
Rock Shox RECON SILVER RL 100MM
Drivetrain
Rear Derailleur
Shimano Deore M6100, SGS
Shift Levers
Shimano Deore M6100
Cassette
Shimano Deore M6100, 10-51T
Chain
Shimano Deore M6100
Chain Guide
GW 1x flip guide
Pedals
Flat Pedals
Wheels
Front Hub
SHIMANO TC500
Rear Hub
SHIMANO TC500
Rims
Alex rim DP30-F 29
Tires
MAXXIS 29 x2.4 Ardent EXO
Brakes
Brakes
Shimano MT-200, 2-piston
Brake Levers
Shimano MT-200, 2-piston
Cockpit
Stem
ROSSIGNOL MTB stem 31,8mm
Handlebar
ROSSIGNOL MTB handlebar 780mm
Grips
Rossignol diamond grip lock-on
Headset
ZS (ZS44/28.6-ZS56/40) / (NO.57)
Seat
Saddle
VELO MTB SADDLE
Seatpost
KS EDGE I
Motor & Battery
Motor
Shimano STEPS MTB EP6
Battery
Shimano STEPS E8036 (630 Wh) S size model with 504Wh battery
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.482 mm | 1.417 mm |
| Front Center | 717 mm | 752 mm | 772 mm |
| Rake | 50 mm | 50 mm | 51 mm |
| Trail | 92 mm | 92 mm | 90 mm |
| Stack | 649 mm | 649 mm | 649 mm |
| Reach | 403 mm | 438 mm | 458 mm |
| Top Tube Length | 590 mm | 614 mm | 627 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 430 mm | 470 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1160 mm | 1195 mm | 1216 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
